Small Dural Mechanical / Hydraulic Wood Chipper With CE Approved
- T/T L/C D/P D/A
- 7 days
You May Like
-
Small Capacity Poultry Wood Pellet Mill With Automatic Lubricant Pump
-
Straw , Cotton Stalk , Rice Husk Industrial Wood Pellet Machine With Double Loop Ring Mold
-
Biomass Energy Wood Pellet Making Machine For Home / Small Process Plant
-
Flat Die Wood Pellet Making Equipment , Sawdust Wood Pelleting Machine
-
High Output Industrial Ring Die Wood Pellet Mill For Fuel Pellets , 30kw
-
55kw / 380v Straw Dust Wood Pellet Mill Waste Paper Wood Granulator
Product Details
| Brand Name | WHOLLY | Place of Origin | China | |
| Model Number | DH30 |
Product Description
Certification:CE
Small Dural Mechanical / Hydraulic Wood Chipper With CE Approved
Quick Detail:
1. CE approved
2. Durable Chromium CR-12 blade
3. Dual hydraulic automatic feeding or mechanical feeding
4. 7-12 CBM/H efficiency
Description:
1. 3PL wood chipper, driven by tractor PTO
2. Cutting diameter size 1cm~25cm, up to 8 inch, 7-12CBM/H cutting capacity.
3. Discharge hood can rotate in 360 degrees. Easy swivel discharge chute.
4. Feeding system: DH30 with double hydraulic motor feeding system.
5. 2 year warranty, heavy duty cast steel bearing housings. 3 blades, round disc housing, easy to change blades and belts.
Applications:
The small chips made by the wood chipper can be used for animal bedding, for the forestry and soil protecting, for new energy making, for compost and forcharcoal. Some customers use their colored garden waste chips, cover the soil and made the garden beautiful; some of them use the garden waste chips in the fireplace.
Specifications:
| Model No | DH-30 |
| Power | 30HP |
| Engine | 3 cylinders diesel engine with electric start |
| Max Diameter of feeding | 8” diameter (200mm) |
| Feeding system | Mechanical / hydraulic |
| Rotor plate size | 680mm |
| Rotor plate weight | 85KG |
| Knives (blades) number | 1 stationary knife (blade), 2 movable knives (blades) |
| Materials of blades | Durable Chromium CR-12 |
| Dimension of discharge hopper | 1780x1100x1350mm |
| Dimension of feeder hopper | 200x220mm |
| Height of discharge spout | 2000mm |
| Rated RPM | 1280 |
| Rotation Angle of Discharge Spout | 360° |
| Working efficiency | 7-12CBM/H |
| Gross weight | 680KG |
Competitive Advantage:
1. CE approved
2. Baking paint
3. Dural hydraulic feeding
4. Durable chromium CR-12 blade
