400Hz 2.2KW Artware Electrical CNC Stepper Motor , DSP Control High Speed Spindles

400Hz 2.2KW Artware Electrical CNC Stepper Motor , DSP Control High Speed Spindles

* High frequency spindles for automatic tool change.
* Ultra precision ball bearings as hybrid ceramic ball bearings.
* For automatic tool change via BT or HSK tool connection.
* Rotary unions for liquid, minimized coolant supply.

Specifications:

1. DSP control, USB port
2. cast iron steel bed?
3. six high power spindle?
4. imported ball screw and HIWIN square?

Rotating speed: 24000rpm ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?D1:63
Power:2.2Kw ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? L:242
Voltage:380V ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? L1:7
Electric current:7A ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?L2:33
Connect mode:ER20
Tool holder’s diameter:1-13mm(Factory standard: 2 fillings)
Taper hole of spindle runout:≤0.003mm
Mandrel runout:≤0.008mm
Lubricating mode: grease
Cooling mode:water
Bearings mode:2*7005 ? 2*7002
Weight:9.6KG

Spindle mode:NYM85-24Z/2.2
Spindle parametric: ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?Overall size(mm):
Frequency:400Hz ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? D:85

Description:

Tool changing structure is advanced so that the signal and tool changing movement could be reliable and stable.?It adopts four-pole motor-driven system and the ISO20 knife handle,The multichamber protective measure including double-layer sealing device and air sealing conformation can efficaciously provide liquid from getting in and keep Motor Spindle working for a long time. could usually be used in the quick processing of different materials with Φ3~Φ10 blade from 24000rpm to 30000rpm. ?The GMN import bearings and engine oil are used to ensure high performance of the spindle.?GDL80 series Motor Spindle is the automatic tools changing spindle designed by our company.?

Applications:

Applicable scope: This product is suitable for Engraving machine or Engraving and milling machine and Lock industry. It is mainly used for the circular carving and drilling and milling of the matrix, spectacles and jewelry.

Competitive Advantage:

1. little vibration, good stability,?Low noise?, high processing precision

2. Adopt the ceramic core Aerial plug, more safe and reliable
3. Infinitely variable speed transmission for frequency changer with wide speed range
