Flexible PCB,rigid flex PCB, Printed Circuit Board / Multilayer PCB / PCB, Flexible PCB, sales@hitechpcb.com

FPCB

Features:

1) Layers: 1 to 6

2) Base materials: BT, Kapton, G10, FR4, CEM-3

3) Base copper thickness: 1/3oz. to 3oz.

4) Double sided: 0.10mm/0.004 inch

5) Four layers: 0.40mm/0.016 inch

6) Six layers: 0.55mm/0.022 inch

7) Max. panel size: 300 x 400mm

8) Min. hole diameter: 0.20mm/0.008 inch

9) PTH hole tolerance: 0.05mm/0.002 inch

10) Aspect ratio: 6:1

11) Blind or buried via: yes

12) Min. line width: 0.051mm/0.002 inch

13) Min. line spacing: 0.051mm/0.002 inch

14) Min. bonding pitch: 0.181mm/0.007 inch (center to center)

15) Min. SMT pitch: 0.40mm/0.016 inch (center to center)

16) Min. hole registration tolerance (NPTH): ± 0.025mm

17) Min. hole registration tolerance (PTH): ± 0.075mm

18) Min. pattern registration tolerance: ± 0.03mm

19) Min. S/M registration tolerance (LPI): ± 0.075mm

20) Min. annular ring: ± 0.025mm

21) Min. S/M bridge (LPI): 0.1mm

22) Plated gold thickness: 0.025um - 3um

23) Contact way:

Mail: sales(at)

Hitech Circuits is a PCB manufacturer from China and we focus on multilayer printed circuit board; High density PCB /HDI, hard gold board; Flexible board / FPCB; Bergquist Aluminum based board,, the ranging from 1L up to 26L. If you have interest in our service and products, please contact us freely.

(Note: China PCB manufacturer Hitech Circuits Co.,Limited specially produces on multilayer printed circuit board / Multilayer PCB; High density PCB / HDI, hard gold board; Flexible board / FPCB; Bergquist Aluminum based board / MPCB, etc.)
