1R1G1B electronic LED display boards / LED information display 192mm x 192mm
- T/T L/C D/P D/A
- 7 days
You May Like
-
Dynamic Outdoor Full Color LED Display Asynchronous with Simple Frame for Supermarket
-
Electronic Flexible LED Screen / P2.5 SMD LED billboard display 960mm x 960mm
-
Dynamic LED wall screen / video advertising LED display 62500 dots / sqm
-
SMD Advertising stage background LED Screen High Definition 1R1G1B 640mm 640mm
-
Two basic color LED wall panel / railway stations waterproof LED mesh display
-
1R1G1B seven segment Outdoor Full Color LED Display 16mm Pixels With 2 Years Warrany
Product Details
| Brand Name | NFCase | Place of Origin | China | |
| Model Number | AIA-1 |
Product Description
Certification:CE,FCC,MSDS
1R1G1B electronic LED display boards / LED information display 192mm x 192mm
Competitive Advantage:
1 ?Shenzhen Comcreating Co., Ltd is a professional manufacturer engaging in the research and development, production, sales and service of LED display system.
2 ?With the continuous and stable development in the past 8 years, Shenzhen Comcreating Co., Ltd has showed strong competition in the market both in products quality and service.?
3 ?CE approved, ROHS compliant, C-TICK and FCC certificated. We had provided more than 3000 LED displays for more than 50 countris and regions,and gained a great reputation from customers.
?P6 Outdoor Led Screen?Product Detail
? Outdoor HD LED Display leader, mature product, functions two years ahead of competitors, worldwide fantastic projects. Core tech \"King Kong\" series standard Modules help clients upgrade to better resolution. Increase the chance to have the second sales and enhance the relationships with clients.
? Protection rate IP65, installation without frame. Module Style Design, fast installation and easy maintenance with low cost.
? Deep black surface, firm & flat, anti-UV mask, make sure the flatness and no distortion. Power and control system back-up technology solution available.?
Specifications:
|
Description |
Technical parameter |
|
|
Unit module |
Module size |
192*192mm |
|
Pixel pitch |
6mm |
|
|
Pixel density |
27777dots/m2 |
|
|
Pixel configuration |
1R1G1B |
|
|
Led specification |
SMD 3 IN 1 3535 |
|
|
Pixel resolution |
W:32dots*H:32dots |
|
|
Cabinet |
Dimension |
960mm*960mm*150mm |
|
Quantities of module |
25pcs |
|
|
Power supply |
4pcs |
|
|
Thermal discharge |
Fan*2pcs |
|
|
Total weight |
42kg/m2 |
|
|
Best viewing angle |
>6m |
|
|
Temperature |
Storage: -35°C~+85°C |
|
|
Working: -35°C~+85°C |
||
|
Thickness |
15cm can adjustable |
|
|
Remarks: cabinet size can changed, upon project need. |
||
|
Power |
Working voltage |
AC220V/110V±10% |
|
Average power consumption |
200-320W |
|
|
Max. Power consumption |
≤650W/sqm |
|
|
Current |
≤20mA(single LED) |
|
|
Control system |
CPU |
Pentium4 or above |
|
Operating system |
WIN98/2000/NT/XP |
|
|
Control method |
Synchronization |
|
|
Main technical parameter |
Driving device |
Constant Current driver IC |
|
Drive type |
1/4?scan |
|
|
Refresh frequency |
≥300Hz |
|
|
Grey scale/colors |
256 levels of each color(R/G/B)/16.7M color |
|
|
Brightness of white balance |
More than 6500cd/sqm |
|
|
Brightness adjustment |
256 levels of each color(R/G/B)by software |
|
|
Operating ambient humidity |
10%--95% |
|
|
Video signal |
PAL/NTSC |
|
|
Control system |
DVI display card+full color controller card |
|
|
MTBF |
≥10,000hours |
|
|
Life span |
≥100,000hours |
|
|
Flatness |
