Product Details
Brand Name | Phovolt | Place of Origin | China | |
Model Number | FD020W |
Product Description
Certification:CE,RoHS,SAA,Ctick
Outdoor LED Flood Lighting, Waterproof 20W COB LED Flood Light For Lawns, Landscaping Lights
Outdoor IP65 Waterproof 20W COB LED Floodlight with CE Waterproof driver, 50000 Hours Lifespan, 3 years warranty
20W COB LED Floodlight Description:
20W COB LED Floodlight adopts high pureness machined aluminum housing, CE approval waterproof driver and Bridgelux(or Epistar) high efficiency COB LED module. It is popular in outdoor lighting, where it has high waterproof requirement.
20W COB LED Floodlight Features:
1. Material: Die-casting aluminum, glass and surface polyester electrostatic spraying
2. Long lifespan: 50000hs
3. Low power, energy-saving rate remains high, belongs to surface light source, light source high utilization rate.
4. The light source color is good, light is soft, luminous efficiency.
5. Cold light source, no infrared or ultraviolet radiation, both in the visible spectral range, without harmful metals mercury, green environmental protection.
6. Voltage: AC85-265V available DC12V or DC 24V 50-60Hz
8. Waterproof grade: IP65
9. Warranty: 3 years
20W COB LED Floodlight Specification:
Rated Voltage |
AC85-265V 50-60HZ |
Total Harmonic Distortion (THD) |
≤9% |
Power Factor |
>0.9 |
Power Efficiency |
>83% |
LED Chips |
Epistar/Bridgelux |
LED Quantity |
1 pcs of COB LED |
LED Power |
20W |
System Power |
24W |
LED Efficiency |
100LM/W |
Light Efficiency |
>85% |
Uniformity |
>0.6 |
Led Initial Flux |
1350-1400LM |
Average Illuminance |
16LUX@3M,8LUX@4M,5LUX@5M |
Color Temp. |
2700-7000K |
CRI |
>70 |
Junction Temp. |
<80℃ |
Operation Temp. |
-40~+55℃ |
Storage Temp. |
-25~+65℃ |
Protection class |
IP65 |
Lamp Shell Color |
Black/Silver/White (optional) |
PIR Sensor |
Available |
Dimension |
180*140*120mm |
Wiring(Default) |
Brown->L, Blue->N, Yellow & Green->G |
Net Weight |
2.8KG |
Lifespan |
>50000H |
Warranty |
3 Years |
Certificate |
CE,RoHS,SAA,Ctick |
20W COB LED Floodlight Applications:
Widely used in factory, gymnasium, boat yard, billboards, buildings, lawns, landscaping, offices, the site of light project and decorative lighting projects etc.
20W COB LED Floodlight Dimension:
20W COB LED Floodlight Photometric:
