Ultrahigh Precision Transformer Oil Purifier/Oil Filter/ Oil Filtration Machine/Oil Separator

ZYD Ultrahigh Precision Transformer Oil Purifier/Oil Filter/ Oil Filtration Machine/Oil Separator

Brief Introduction
With double-stage vacuum system, two vacuum separating chambers and molecule adsorption technology, This Ultrahigh Precision Transformer Oil Purifier/Oil Filter/ Oil Filtration Machine/Oil Separator can increase the purification effectiveness more than three times and efficiently and completely dewater, degas, remove particles from transformer oil, mutual inductor oil, switch oil  to get higher dielectric strength and optimize performance of the oils.

Competitive Advantages:
1.The double-horizontal vacuum evaporation containers enlarges the evaporation area and extends the flowing distance of the oil.Thus this transformer oil purifier can increase the oil filtration effectiveness more than three times and efficiently and completely dewater, degas, remove particles from transformer oil, mutual inductor oil, switch oil  to get higher dielectric strength and optimize performance of the oils.

2.The filtering materials with varied apertures are made of specialized glass fiber.The sizes of the filtering fiber and aperture shrink gradually in  different filtering stages. And impurities with different sizes are filtered step by step.Thus  the capability of removing impurities is improved greatly by this method.

3.Efficient heating system to make heating uniformity and decrease power consumption. The heater will stop automatically when the oil temperature reaches a certain degree.

4.The oil-level floating ball and double-infrared liquid level automatic controller are installed to control the oil level and avoid the oil leaking.

5. Having interlocked protective system, pressure protective device which will avoid overload, supervoltage, blank pumping, blank heating, oil leak and electricity leak etc.If there has any fault, this transformer oil purifier will be power off automatically.

As per the customer's specific requirements, we can manufacture trailer-type transformer oil purifier with closed structure(ZYM Trailer-type vacuum transformer oil purifier).
