Vibration Tester AV-160B

Brand Name	AM		Place of Origin	China
Model Number	AV-160B

Product Feature * Can display the parameters of “Displacement”, “Velocity” and “Acceleration” simultaneously. * In accordance with ISO 2954, used for periodic measurements, to detect out-of-balance, misalignment and other mechanical faults in rotating machines. * Specially designed for easy on site vibration measurement of all rotating machinery for quality control, commissioning, and predictive maintenance purposes. * Individual high quality accelerometer for accurate and repeatable measurements. * Wide frequency range (10Hz~10kHz) in acceleration mode. * AC output socket for headphones and recording. * Optional headphones for use as electronic stethoscope. * Bearing condition monitoring function. * Use USB data output with connection PC. * Provide Bluetooth data output choice. Product Parameters Transducer Piezoelectric accelerometer Accuracy ±5%+2 digits Measurement Range Displacement : 0.001-4.000 mm equivalent peak-peak / 0.04-160.0 mil Velocity : 0.1-400.0 mm/s true RMS / 0.004-16.00 inch/s Acceleration : 0.1-400.0 m/s2 equivalent peak / 0.3-1312 ft/s2 / 0.0-40g Frequency Range Displacement : 10Hz. ~ 1kHz. Velocity :10Hz. ~1kHz. Acceleration: 10Hz. ~ 10kHz. Operating Conditions Temperature : 0-50 ℃ Humidity : below 95% RH Analogue Output AC output 0~2.0V peak full scale (load resistance: above 10k) Power Supply 4x1.5vAAA (UM-4) Battery Size 140x70x30mm Weight 130g (Not including Batteries)?
