2.5m UV flatbed printer

?  The Main Technical Characteristics of ZY-SK-UV2500A:

Zhongye UV series UV flatbed printer adopts Japanese series print heads, equipped with double servo drivers, 5cm max printing height. Realize the formless, non-contacting, and real-time printing on different kinds of sheet materials and roll materials, such as KT board, PVC board, plexiglass, glass, ceramic, metal, and leather etc. It replace the roll of traditional screen printing technology, and brings to customers the individualized, small-lot, various, and multicolored products, with the output features of speediness, high efficiency and flexibility guaranteed.

?  The main parameter and standard of ZY-SK-UV2500A:

Name: UV2500A
Class: ZY-SKUVA series
Print technology: Drop-on-demandPiezo electric
Printhead: 4/5/7/10(spt255)
Print width: 2.50M
Print heigh: 5cm
Resolution: 1440dpi max
Speed: 2pass 42m²/h ;4pass 28m²/h ;6pass 12m²/h
Locating mode: Raster /servo
Color: CMYK W LC LM
Media width: 3.2M
Media handl: Roll to roll   Sheet to sheet
Media types: KT board;PVC board;Plexiglass board;glass board;ceramic board,tile;metal board;leather and all the roll to roll material like flex banner,mesh,one way vision,vinyl etc
Drying system : Uv lamp
File format: TIFF,JPEG,Postscript 3,EPS,PDF
Working process: Printmon software for windows xp
Rip: Photoprint /maintop
Power supply: 50hz/60hz 220v(10%)20A
Operation environmeng: (Tempperature )18-26(Humidity )40%-70%
Dimesion: 4.5m*1.6m*1.4m
Weight: 1000Kg/1200KG

? Configuration below is according to different models:

1.Motor: Japanese Panasonic, Fuji AC servo motor;
2.Rail:Japanese THK,Tawinese HWIN;
3.Heating system:front&back double heating;
4.Feed-in&take-up system:IR controlled auto feed-in&take-up system;
5.Printhead cleaning system: positive pressure, vaccum
6.Ink system:German KNF ink supply system,Japanese negative pressure system

? Quality Guarantee and after sale service:

1. 1 Year Warranty ( without printheads and consumable spare parts of ink system )
2. With the printer, we send you One free spare parts kit including all the consumable spare parts; Software CD and Demo VCD and manual freely. You can learn how to install the machine from the vedio we sent to you.
3. Our engineer can go to clients'place to install the printer as client demanding and teach the client how to operate and maintain the machine. All the service is free. The client only need to pay the air ticket and accommodation charge.
4.Two of our engineers who is English-spoken & progfessional of techinical are on line 24 hours. They can offer you on-going service and solve the printer problem at anytime!
