JCUT CNC woodworking machine CNC router machine

Brand Name	JCUT		Place of Origin	China
Model Number	jcut1325B

JCUT- 1325B (51''x98'') Wood CNC Router
Features: Optional (vacuum (vacuum (vacuum
1) Machine body: Whole cast iron
2) Guideway: XYZ-axis use linear guideway
3) D riving mode: Rack
4 ) Work dimensions: 1, 3 00 mm x 250 0 mm x 80mm (
5 ) Body dimensions: 1, 7 00 mm x 32 00 mm x 1, 65 0mm (with bracket)
6 ) Z-axis working area: 80mm (or 150mm)
7 ) Max. Feeding height: 120mm or bigger
8 ) Cut thickness of material: ≤ 40mm
9 ) Max. Speed: 25, 000mm/min
10 ) Working speed: 0 - 8, 000mm/min
11 ) Mechanical precision: 0.01mm
1 2 ) Software: Type 3 software, Artcut software, Artcam software
1 3 ) Max. Power consumption: 3 kW
1 4 ) Power source: AC 220/50 /60 Hz (or 110v/60Hz)
1 5 ) Driver type: Stepper motor (XZ-85BYG, Y-axis use two 85BYG motors)
1 6 ) Memory: Without or (DSP)
1 7 ) Spindle: 2.2 kW (100mm) variable speed, water cooled motor ( 3kW, or bigger
1 8 ) Spindle speed: 0 - 24, 000rpm /min
1 9 ) Blade diameter: 3.175mm, 4mm, 6mm ( or 8mm, 10mm, 12mm, 12.7mm )
20 ) Control system: (NCSTUDIO) or DSP (USB interface)
21 ) Command: G code, u00, mmg, plt
2 2 ) Running circumstance temperature: 0 - 45 ° C
2 3 ) Relative humidity: 30% - 75%
Packing:
Pack dimensions: 1, 75 0 x 30 00 x 1, 75 0mm
Net weight: 110 0kg (with bracket)
Gross weight: 1300 kg

Applications:
Can be used on advertisement engraving, advertisement cutting, stone processing
Cutting, Cu and Al molding cutting, mold manufacturing cutting, wood processing cutting,
Wood door manufacturing cutting, craft manufacturing cutting, light box cutting, building
Mold cutting, indoor decoration cutting, wave board processing cutting, light equipment
Mold processing cutting, sign and mark manufacturing cutting,
