Sell PVC Door-Window 2-Head Welding Machine

Place of Origin	China

Model No.:HJ2-3500
Product Origin:China
Brand Name:Parker
Price Terms:
Payment Terms:
Certification:
Description:Technical parameters: 1) Input power source: 220V, 50Hz 2) Total power: 1.2kW 3) Working air pressure: 0.5-0.8MPa 4) Air consumption: 100L/min 5) Welding height: 20-120mm 6) Max. welding width: 120mm 7) Welding size: 400-3,500mm 8) Dimensions: 4,500 x 1,000 x 1,700mm 9) Weight: 870kg This machine is made up of two heads, frame, electric controller box, and profile-holding frame. The left head can move 20mm by following the track. Every head has their separate location structure, pressing structure, heating structure and head box. This machine is one of the necessary equipment for processing PVC windows and doors. It can complete the whole welding alone. It features advanced technique, pneumatic drive, PC control, stable capability and simple operation. The CM non-oil lubricating bearing and linear moving bearing make high precision and convenient maintaining. The machine has one head that can weld various angles. The two heads can work individually and jointly.
