Small Sachet Packing Machine Automated Packaging Equipment With Ribbon Printer

Single-Line 3-Side Sauce Packing Machine

I.: Main feature:

This model adopts advanced Mitsubishi PLC control system and easy to maintain and operate. It can automatically finish the process, such as filling, measurement, bag making, sealing, cutting, date coding, counting.

II.: Specifications:

III.: Description:

1.?Sealing?type:?three-side?sealing packing?method.??

2.?Operation:?packing?running?data?and?adjustment?are?directly?displayed?on?the?display.?The?user?can?directly?operate?it?on?the?displayer.

3.?Founction:?making?bag,?metering,?filling,?sealing,?cutting,?counting?and?printing?batch?number.

4.?Body?material:?304?stainless?steel.

5.?Filling?type:?measurement piston pump;

6. This machine can finish measuring, pulling, feeding, forming, cutting automatically.

7. Chinese-English operating screen display, easy operation and maintenance.

8. Mitsubishi PLC control system insure steady working conditions, and available to adjust any parameter without stopping the machine.

9. Adopt step motor to pull film, more accurate.

10. Independent temperature control system, precision±1 degree.

11. Independent control of horizontal / longitudinal temperature, to ensure a good fit of various kinds of complex film.

12. Automatic alarm protects system, to save the waste into minimum limited.

IV.: Applications:

V.: Information we need:

To make an exact quotation for the granule products, it would be better if you could provide us information with following:

1. What kind of product you want to pack?

2.?How many grams in one bag?

4. What is the bag size?

5. What kind of sealing form/bag shape?
