High Precision Petrochemical Industry Studded Tubes NPS 4'' 114.3mm
- T/T L/C D/P D/A
- 7 days
You May Like
-
DIN 17175 St35.8.I or P235GH TC1 Welded Stud Pipe for Furnace
-
Extruded Bimetal Refrigeration Fin Tube , A210 Gr A1 / C SMLS Carbon Tube
-
DIN 17175 St35.8.I or P235GH TC1 , SML Tubes DN40 48.3mm Stud Welding Tube
-
10# 20# 16Mn 20G 12Cr1MoVG H Fin / HH Fin Welded Heat Exchanger Tubes
-
A179 Cold Drawn Seamless Carbon Steel Heat Exchanger Fin Tube OD 1\'\'
-
Continuous Helical Welded Heat Exchanger Fin Tube SA213-TP304H NPS 2\'\' X SCH80S
Product Details
| Brand Name | Reliance | Place of Origin | China | |
| Model Number | Studs |
Product Description
Certification:SGS, ABS, BV, TUV…
SA335 P11 / P22 / P91 from BaoSteel , NPS 4\'\'(114.3mm) studded pin heating tubes
ASTM A335/A335M:?Seamless Ferritic Alloy-Steel Pipe for High-Temperature Service
|
General Studded Tubes?production capacity |
General specifications of?Studded Tubes tubes |
|
Production facility: 3 finning machines; Daily capacity up to 80,000 studs; |
Tube OD: 219 mm max. Tube Thickness: 4mm~15mm Tube Length: 16 meters max. Studs OD: OD6mm~OD16mm Studs Height: 10mm Min. |
Manufacturing process:
Studs are fully automatically welded onto the tube by resistance welding.
Acceptance criteria
Approved drawings and the delivery conditions (TDC) of clients.
Delivery condition
Tube ends are square cut, free burrs, internally dried and air blown clean, externally coated with varnish at both ends of extruded bimetallic fin tube.
Surface Protection:
Oil dip, black?coating or varnish.
Type of Studs
Cylindrical or?elliptical
Documentation
It shall include raw materials mill certificates, inspection and test samples results and warranty certificate of manufacturer.
Applications:
Furnace Chemical Petrochemical industry Power station etc.Specifications:
| Items | General Materials | Popular ASTM /ASME Materials |
| Core Tube Material |
?Carbon Steel? ?Alloy Steel ?Heat ?Resistant Steel, ?Stainless Steel |
1. Carbon Steel: A106 Gr.?B 2. Stainless Steel: TP304/304L,TP316/TP316L, TP347 3. Alloy Steel: P5,T5,P9,T9,T11,T22 |
|
Studs Material? |
?Carbon Steel? ?Stainless Steel |
1. Carbon Steel? 2. Stainless Steel:? ? ? ?TP409/410,TP304/304L,TP316/TP316L,?TP321/TP321L |
Dimensions Data Sheet?We\'re Supplying.
|
? General Descriptions of Studded tubes |
Popular Specifications we make |
|
Tube OD(mm) |
OD38mm~OD219mm |
|
Tube Wall Thickness(mm) |
4mm~15mm |
|
Tube Length(mm) |
16,000mm Max. |
|
Studs OD(mm) |
OD6mm~OD16mm |
|
Studs Height(mm) |
10mm~45mm |
|
Please email us for more information as your request. |
Competitive Advantage:
We have more than 10,000 square meters workshop, including 3 finning machines, daily extrusion capacity up to 80,000 studs. Shanghai Port is our nearest seaport and airport, less than 2 hours’ drive away from our workshop, convenient transportation. Due to their high rigidity, studded tubes can be used even under extreme temperature and pressure conditions.Contact Us
