Home > Products > Digital LED Billboard > P8 RGB Waterproof Mobile Digital LED Billboard Outside W 40 H 40 dots
P8 RGB Waterproof Mobile Digital LED Billboard Outside W 40 H 40 dots
- T/T L/C D/P D/A
- 7 days
You May Like
-
Waterproof Stadium LED Display / Programmable LED Signs For Advertisement
-
P10 Full Color LED Sign / High Definition Commercial LED Display For Outside
-
P10 DIP Commercial Electronic Digital LED Billboard Dynamic Convenient
-
Electronic Advertising Full Color Digital LED Billboard For Roadside
-
Renta Commercial LED Displays / Advertising Truck Mounted LED Screen
-
Energy Saving RGB Outdoor LED Billboard / Rental LED display For Public
Product Details
| Brand Name | Ocolour | Place of Origin | China | |
| Model Number | OC-FA-P8SMD3535 |
Product Description
Certification:CE/RoHS/FCC/ETL/TUV
P8 RGB Waterproof Mobile Digital LED Billboard Outside W 40 × H 40 dots
?
Quick Viewing:
Physical density: 1452dots per sq.ft (15625 dots per sq.m);
Module pixel configuration of W 40 × H 40 dots;
Module size is W 12.60 X H 12.60 inch (W 320 × H 320 mm);
Maximum power consumption is less than 89.12W/sq.ft (960W/㎡);
With high brightness of 511CD per square feet (5500 CD per square meters);
-30oC to +60oC of working temperature;
Color temperature is from 3000K to 9000K and adjustable;
Waterproof is IP65 for lamp & top, other part: IP54.
?
Detailed Description:
With unique water-proof design, the cabinet is qualified for IP65 defend level and is able to be installed in outdoor.
With the brightness higher than 5500cd/M2, our outdoor LED display is able to be installed in different environments. Besides that, our display can change the brightness automatically upon the multifunctional card.
On the aspects of design, we confirm environmental protection and energy saving philosophy.
Supporting remote wireless and lined centralized control management, one monitor center is able to control several LED Advertising Billboards Displays.
??
Popular Application:
Outdoor LED Billboards display screen is used for outside advertising, like park, public event, building, school, etc.
?
Specifications:
|
Item |
Technical Parameters |
|
Screen model |
OC-FA-P8SMD |
|
Led encapsulation |
SMD3535 |
|
Led configuration |
1R1G1B |
|
Pixel pitch(mm/inch) |
8mm / 0.31 inch |
|
Red chip |
Wavelength range: 619-628nm, 5nm; |
|
Green chip |
Wavelength range: 461-470nm, 4nm; |
|
Blue chip |
Wavelength range: 522-531nm, 4nm; |
|
Resolution |
1452dots/sq.ft (15625dots/㎡) |
|
Maintenance |
Front-maintained |
|
Brightness: CD/sq.ft (CD/㎡) |
>511CD/sq.ft (5500 CD/㎡) |
|
Refreshing frequency: Hz |
>960 Hz |
|
Grey scale |
14bit |
|
Module pixel |
W 40 × H 40 dots |
|
Module size |
W 12.60 X H 12.60 inch (W 320 × H 320 mm) |
|
Viewing angle |
Horizontal: 120°, Vertical: 120° |
|
Cabinet material |
Aluminum/steel |
|
Lightness uniformity |
Pixel & module>90% |
|
Cabinet color |
Customized |
|
Driving method |
1/5 scan constant current |
|
Driving IC |
MBI5041/MBI5024/JXI5020 |
|
Cabinet size |
Cabinet size could be adjustable by demands |
|
Power supply |
85-264VAC, typical value: 110VAC/220VAC |
|
Max consumption |
Max.≤89.12W/sq.ft (960W/㎡) |
|
Average consumption |
Ave.: 29.73-44.59w/sq.ft(Ave.:320-480w/㎡) |
|
Led life time |
≥100000hours |
|
Mean time to failure |
≥5000hours |
|
Module plainness |
≤1mm |
|
Pixel out of control |
less than 1/ 10??, dispersion state |
|
Working temperature |
-30oC to +60oC |
|
Working humidity |
20% to 90% |
|
Waterproof IP |
lamp & top:IP65, other part:IP54 |
|
Protection function |
dampproof/dust-free/anti high temp/anti-thunder/ anti electromagnetic interference, etc |
