Extruded Tungsten Carbide Rod
- T/T L/C D/P D/A
- 7 days
You May Like
-
Fully Ground HSS Straight Shank Twist Drill Bit
-
SO RF Flanges,WN RF Flanges ,SW RF Flanges , BL RF Flanges , Screwed Flanges , Long Weld Neck Flange
-
Customized Available Beatiful Durable Aluminum Alloy Hasps
-
DIN1897 HSS Twist Drills Bits
-
Aluminum Alloy Ambulance Patient Stretcher Trolley Dimension Adjustable
-
HRC45 3 Flutes Carbide Square End Mills With TiAlN Coating
Product Details
| Brand Name | INMIND | Place of Origin | China | |
| Model Number | Standard Length type 1mm to 32mm |
Product Description
Certification:SGS Factory Certificater
Custom SK30UF Alloy Tungsten Carbide Rod Extruded with Two Spiral Hole
Quick Detail:
Inner Cooling
Two Spiral Holes
Unground
Extruded Rod.
We also accpet other fixed length Rod: 50,60,75,100,150,200mm
Popular Grade is :SK30UF.
We supply the Lead Data for each size ,also the distance of holes and Diameter of hole.
From Diameter 6mm to 32mm.
Description:
Ultra-Fine Mirco grain Size ,good quality cemented carbide rod,SK30UF is popular grade ,Equal to KFC K40UF.We supply the Lead Data for each size,also the distance of holes and Diameter of hole.From Diameter 6mm to 32mm.
Applications:
Suit for High-temperature alloys,stainless steels,Titanium,Quenched steels,Taps,etc.To make inner cooling? drills, reamer,End Mills and so on.Middle-High Speed.
Specifications:
Material Properties and Applications
|
Grade |
Co% |
Hardness HRA |
Desity g/cm3 |
Flexural Strength MPa |
Wc Grain Size(um) |
Application |
|
SK10F |
6 |
94 |
14.72 |
3950 |
0.3-0.4 |
Fit for Copper and Alumimium,PCB,glass fiber reinfored compasites,braking materials,graphite ,etc. |
|
SK20F |
8 |
93.1 |
14.65 |
4000 |
0.3-0.4 |
Suit for stainless steels,quenched steels(Hardness>HRC60),Glass Fiber Reinforced composited,especial for high-speed milling and dry milling. |
|
SK20N |
8 |
93.8 |
14.6 |
3700 |
0.3-0.4 |
Suit for stainless steels,quenched steels(Hardness>HRC60),Glass Fiber Reinforced composited,especial for high-speed milling and dry milling. |
|
SK30N |
10% |
91.5 |
14.35 |
3200 |
0.8 |
Strong General purpose,Suit for gray cast iron,cast iron,steel,copper,Aluminium,etc. |
|
SK30F |
10% |
91.8 |
14.45 |
3500 |
0.6-0.8 |
Strong General purpose,Suit for gray cast iron,cast iron,steel,copper,Aluminium,etc. |
|
SK30UF |
10% |
92.1 |
14.4 |
3900 |
0.6 |
Strong General purpose,Suit for gray cast iron,cast iron,steel,copper,Aluminium,etc. |
|
SK40N |
12% |
92.3 |
14.2 |
4000 |
0.5-0.6 |
Suit for High-temperature alloys,stainless steels,Titanium,Quenched steels,Taps,etc.Middle-Speed. |
|
SK40F |
12% |
92.5 |
14.1 |
4100 |
0.4 |
Suit for High-temperature alloys,stainless steels,Titanium,Quenched steels,Taps,etc.High Speed,Middle Feed. |
International Material Grade Comparision Table
|
INMIND Grade |
