Spherical Welding Frp Stainless Steel Pressure Vessels Painting Industrial

steam storage tank?Stainless Steel Pressure Vessel Compressed air tank

Stainless Steel tank series strictly tally with?the requirements of GB150-98 Steel Pressure Vessel and JB/T4735-97 Steel Welding Normal Vessel.

1.Heat preservation material of the vessel adopt high-temperature resistant and anti-aging? polyurethane blister or per cotton.
2.Joints adopt international general ISO package chuck,inner container adopts?imported?stainless steel SUS 304 or SUS316 ,internal surface polishing.

All is in accordance with? GMP medical standards.
3.Orifice is set with level gauge (static-Pressure type,capacitance type,non-contac type ,ultra-soni

type and glass tube), air respirator,thermometer,(digital display type or dial plate type), CIP cleaning mouth , SIP sterilizing mouth, liquid entrance-exit gate and? sanitary inlet.

4.Volume Specification:100L-30000L or to be designed and manufactured? at customers?actual

request.

5.Relevant GMP Testing at data are attached in the machine.Including material report, external?components certificate of quality and verification form.

Quality control for compressed air tank

1.The?raw?materaial?plate?was?anlysised?by?our?material?anlysier?to?assure?the?quality

2.The?welding?is?argon?arc?weld(TIG)?to?avoid?plate\'s?oxidized

3.After?welding?the?the?inner?tank?,we?will?make?a?full?water?pressure?test?to?check?the?welding?joint?.After?welding?the?jacket?,the?full?water?pressure?test?be?done?for?jacket?too

4.After?finishing?the?surface?finish?,our?people?will?make?a?surface?roughness?testing?to?assure?the?data?.

5.After?agitator?installment?,we?will?operate?it?to?assure?the?function?is?good?.

6.The?nozzle\'s?position?\'s?confirm?also?is?checked?by?our?quality?control?people?.

Main Technical Parameters

1.?Dimension: Diameter and height according to the requirements?
2.Material: Stainless Steel (304 or 316L)?
3.Tank shell thickness: 2mm or more (according to the design or customer required)?
4.?Pressure (MPa): Atmospheric pressure-Middle pressure (According to the Chinese Design standard)?
5.Function: presure vessel?storage tank?
6.Design temperature C-degree: 0-200
7.Tank surface: The original surface of the stainless steel plate (or polishing if required)?
8.Operation plate form: We can design the plate form if required.?
9.General accessories(If required): Manhole, CIP, respirator, sight glass?

10.Manufacture standard: Chinese Pressure Vessel Design and Making Standard?
11.Guarantees inner quality and safety, good looking appearance and function by introducing international advanced large-sized equipment of pulse plasma arcwelder and auto polishing machinery and cooperating with international famous finished.

Specifications

1.Volume:100-30000L?
2.Sanitary Tank:No Dead Corner?
3.Factory Price?

Typical Application

Wine,Beer Juices Food &?Beverage Pharmaceutical

Biotechnology & Laboratory Medical & Medical Device Chemical

Industry painting Industrial
