P10 Outdoor LED Full Color Display Screen

FOB Price

USD $800 - $2000 / Piece

1 Piece(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	SZADDTECH		Place of Origin	China
Model Number	P10

P10 Outdoor LED Screen
Technical Specifications
LED Lamp Parameters
No.	Item	Specifications
1	LED lamps	DIP346 , Oval
2	Wavelength	Red LEDs	620-630nm
Green LEDs	520-535nm
Blue LEDs	465-475nm
LED Module Specifications
1	Pixel Pitch	10mm
2	Pixel Configuration	1R1G1B
3	Module Resolution	16dots X 16dots
4	Module Size	160mm x 160mm
LED Cabinet Specifications ( Standard Cabinet )
1	Cabinet Size(WxH)	960mm x 960mm
2	Cabinet Resolution	96 x 96 pixel dots
3	Module Quanity	36 PCS
4	Cabinet Frame Material	black powder coated steel
5	Cabinet Weight	55 Kg
Screen Parameters
1	Screen Resolution	10,000 dots/㎡
2	Screen Brightness	8000 nits
3	Brightness Adjustment	manually or automatically
4	Driving Method	constant current 1/4
5	View Angle	Horizontal 110° Vertical 60°
6	Optimum Viewing Distance	5m to 200m
7	Refreshing Frequency	1500 Hz (Adjustable by Software )
8	Input Voltage	AC220V/50Hz or AC110V/60Hz
9	Power Consumption	Max.: 1200 W/㎡ Average: 400-800 W/㎡
10	Defects Rate	≤0.00001
11	MTBF	>5000 hours
12	Lifespan	≥100,000 hours
13	Protection Grade	IP65
14	Temperature-operating	﹣40℃~+60℃
15	Humidity-operating	10%~95%
16	Operating System	Windows98/me/2000/NT/XP
