Outdoor Full Color LED Display

FOB Price

Negotiable / Piece

3 Pieces(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	ADDTECH		Place of Origin	China
Model Number	P20

P20 Outdoor LED Full Color Display
Technical Specifications
LED Lamp Parameters
No.	Item	Specifications
1	LED lamps	DIP546 , Oval
2	Wavelength	Red LEDs	620-630nm
		Green LEDs	520-535nm
		Blue LEDs	465-475nm
LED Module Specifications
1	Pixel Pitch	20mm
2	Pixel Configuration	2R1G1B
3	Module Resolution	16dots x 8dots
4	Module Size	320mm x 160mm
LED Cabinet Specifications ( Standard Cabinet )
1	Cabinet Size(WXHXD)	1280mm x 960mm
2	Cabinet Resolution	64dots x 48dots
3	Module Quanity	24pcs
4	Cabinet Frame Material	black powder coated steel
5	Cabinet Weight	57.6KG
Screen Parameters
1	Screen Resolution	2500 dots/㎡
2	Screen Brightness	5500mcd/㎡
3	Brightness Adjustment	manually or automatically
4	Driving Method	constant current static
5	View Angle	Horizontal 110° Vertical 60°
6	Optimum Viewing Distance	20m to 300m
7	Refreshing Frequency	≥180Hz
8	Input Voltage	AC220V/50Hz or AC110V/60Hz
9	Power Consumption	Max.: 1000W/㎡ Average: 400-800W/㎡
10	Defects Rate	≤0.00001
11	MTBF	>5000 hours
12	Lifespan	≥100,000 hours
13	Protection Grade	IP65
14	Temperature-operating	﹣40℃~+60℃
15	Humidity-operating	10%~95%
16	Operating System	Windows98/me/2000/NT/XP
Packaging Details
1	packing material	wooden box or flight case
2	screen weight	60Kg/㎡
3	packing way	one case holds one or two cabinets
