PLC Control Steel Floor Deck Roll Forming Machine , Roof And Floor Tile Making Machinery
- T/T L/C D/P D/A
- 7 days
You May Like
-
SJ120 / 33 Single Screw Extruder System For Plastic Construction Board Extrusion Line
-
PMMA Multi-Layer Pvc Plastic Sheet Extruder Line / Making Machine High Production Efficiency
-
PC , PP , PE Hollow Sheet Extrusion Line / Plastic Sheet Extruder With Single Screw 2100mm 1300mm
-
Plastic PP Single Wall Corrugated Pipe Production Line / Extrusion Machinery
-
WPC Board Production Line Twin Screw Extruder Plastic Extrusion Machines
-
single screw extruder hdpe pipe machine with price
Product Details
| Brand Name | Guangcai | Place of Origin | China | |
| Model Number | GWC76-305-915.A |
Product Description
Certification:CE
PLC Control Steel Floor Deck Roll Forming Machine , Roof And Floor Tile Making Machinery
Quick Detail:
Composition
This floor deck roll forming machine consists of several parts, as listed below.
?
1. 5T decoiler
2. roll forming machine
3. Hydraulic shear
4. Hydraulic station
5. PLC control cabinet
6. run out table
Working process:
Passive decoiling → guided material feeding → roll forming → cut-to-length → run out
Description:
The floor deck roll forming machine contains many models, but they have something in common as demonstrated below.
Features
1. The feeding width of our machine is 1000mm. So, there is no need to slit the steel coils that are directly bought from the raw material market, thereby making full use of the steel.
2. This is a pretty mature product, and redesign process is completely unnecessary for the models that have been fabricated by us, thus largely shortening the production cycle. In addition, the floor deck roll forming machine is customizable.
Applications:
workshop warehouse hangar gymnasium theatre exhibition hall engine house industrial buiding civilian buidingSpecifications?
| Model | GWC65-185-555 | Note |
| Applicable material | Galvanized plate | This machine is customizable upon each customer\'s requirements and the characteristics of processed material. |
| Feeding width | 1000mm | |
| Processing thickness | 0.7mm - 1.2mm | |
| Roller material | 45# steel which goes through heat treatment and hard chrome plating | |
| Main motor power / hydraulic station power | 15kW x3 / 7.5kW | These parameters can be set according to the required production capacity. |
| Forming passes | 42 | |
| Forming speed | 5-15m/minute | |
| Machine dimensions | 24×1.3×1.2m | |
| Machine weight | 25T | |
| ? | ? |
