Home > Products > Automatic Straw Making Machine > High Capacity Three Color Automatic Straw Making Machine Pipe Extruder Machine
High Capacity Three Color Automatic Straw Making Machine Pipe Extruder Machine
US$ 12000 - 12500/
/ Square Meter
1 Square Meter(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
2~50pcs Multiple Drinking Straw Packaging Machine with Bopp Film
-
Auto Three Sides Sealing Straw Packing Machine 1.8m0.8m1.7m
-
Double Head Paper Cotton Swab Making Machine With Touch Screen Control Panel
-
380V 50HZ 8kw Baby Cotton Buds Making Machine Plastic Pipe Extruder Machine
-
High Efficiency Paper / Plastic Cotton Swab Making Machine 800-900 pcs/min
-
White Medical Paper / Plastic Cotton Swab Making Machine With Magnetic Valve
Product Details
| Brand Name | Depai | Place of Origin | China | |
| Model Number | DP-DS01-2 |
Product Description
Certification:CE/ISO9001
Energy Saving , Three Color Drinking Straw Making Machine , High Capacity
Description:
DP-DS01 series Three color straw making machine?is composed of main body, tooling, cooling system, cutting machine.
Quick Details:
1 year warranty Labor saving Easy to operate and controlCharacteristics
Wide?application: drinking?straw,?candy?bar,?pen?riffel,?cotton swab stick etc. Easy?to?operate.?One?operator?is?enough?to?run?the?whole?line? Cut?form:?Diversified cut-end:?90°?/90°?,?90°?/45°?,?90°?/60°?,?45°?/45°?,?60°?/60°?Quality?Construction?Throughout
The?gears?and?bearings?are?precision?ground?and?hardened?to?ensure?smooth and?quiet?operations.? The?screw?and?barrel?is?manufactured?from?Aluminum?Chromolybdenum?alloy?steel?and?is?stress?relieved. The die?undergoes?nitride?hardening?treatment?for?a?long?service?time. The?water?tank?and?the?surface?of?cutting?machine?are?made?of?stainless?steel.SPECIFICATION:
| Model | DP-DS01-1 | DP-DS01-2 | DP-DS01-3 |
| Color | Single color? | Bi-color | Tri-color |
| Main parts | Extruder, cooling water tank, hauling & cutting system, (vacuum equipment, aircompressor) | ||
| Power?supply | Main?screw? | 380v, 3phase, 50hz, 7.5kw (VFD)? | |
| Sub-screw | / | 0.75 kw | 0.75 kw×2 |
| Heating | 9 kw | 12 kw | 15 kw |
| Hauling?motor | 0.75 kw(VFD) | ||
| Cutting?motor | 0.75 kw(VFD) | ||
| Total power | 19.5 kw | 23.5 kw | 27.5 kw |
| Temperature?Controller | 5 sets | 8 sets | 11 sets |
| Electric?control?cabinet | 1 set | 1 set | 1set |
| AutomaticCounting?Device | 1 set? | 1 set | 1set |
| Way?of?Hauling? | By?rubber?roller | ||
| Way?of?cutting | Rotatory?cutting | ||
| Cooling?water?tank | Usually?3.5m,?can?be?adjust into 4.5m or 6m? | ||
| Specification of?Pipe |
Material | PP?PE?etc. | |
| Diameter | 2mm~13mm, others can be customized | ||
| Length | Adjustable | ||
| Capacity | 600~1000pcs/min | ||
| Color | Single | Two | Three |
| Straight?or?spiral?strips | √ | √ | √ |
| Cutting?End | 90°/90°,90°/45°,90°/60°,45°/45°,60°/60 | ||
| Optional parts | Vacuum Pump (0.75 kw) | Air compressor (3 kw) | |
| Machine dimension (L×W×H) | 2.2m×1m×1.3m | 2.2m×1.3m×1.5m | 2.2m×1m×1.7m |
| Production line?dimension?(L×W×H) | 9m×1m×1.7m | 9m×1.3m×1.7m | 9m×1.6m×1.7m |
| Weight?of?equipment | 1000 kg | 1300 kg | 1500 kg |
REMARKS:
Packaging method: wooden case or as your requests Loading port: Shanghai, Ningbo or as your requests Delivery time: 7-15 days for goods in stock, 30 days for new Trade?terms: FOB, C&F Payment terms: T/T, L/CCompany Information:?
Hangzhou Depai Machinery Co., Ltd is Specializing in the production of drinking straw machinery for more than 10 years,which becomes the one of largest manufacturers with strong technology in China.
The company is located in Hangzhou, with an advantageously geographical location and convenient transportation.
Our clients cover all around the world. And our machinery have been sold to South America, Africa, and Middle East etc. We have a strong R&D team, making sure our machines with high performance by continuous improving based on the current technology and feedback from customers. In the meantime, We have professional after-sale service system to make sure our machines good, steady and your purchase, use, no worries.
