KYL-210 High Speed Rate Wireless Radio Modem CC1100 Data Module 400m Distance
- 50000 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
KYL-200U Low Cost RF module 433MHz/868MHz/915MHz RS232/RS485
-
KYL-200L 1W Wireless RF Data Module 433MHz RS232,RS485,TTL interface
-
High Speed Rate Wireless Module Low Cost, Small Size
-
10km Wireless Radio Modem 5W, Long Distance
-
1W VHF Radio Module 144MHz, 230MHz Wireless Data and Voice Transmission RS232, RS485, TTL
-
4-way ON-OFF Wireless Control Module, 433MHz Wireless I/O Module
Product Details
| Brand Name | KYL | Place of Origin | China | |
| Model Number | KYL-210 |
Product Description
Data Sheet:
RF power: 50mW
Operating voltage: DC5. 5V or 3.1V
Receive current: less than 20mA
Transmitting current: less than 40mA
Sleep current: less than 20uA
Carrier frequency: 433MHz, also can customize 300 to 350 MHz, 390 to 460MHz and 780 to 925 MHz or ISM others
Communication connects: RS-232/RS-485/USB/TTL selectable
Baud rate: 1200/2400/4800/9600/19200/38400/100kbps
RF line-of-sight Range: 200m(BER = 10-5@9600bps) 400m(BER = 10-5@1200bps)
Size: 40 x 24 x 6mm(without antenna port)
Application:
RTU/SCADA
Process Control Equipment
Natural Gas Automation
Gas Flow Measurement
Flow metering
Tank Gauging
Cathodic protection
Valve control/actuation
Instrumentation
Seismic monitoring
Telecom/Telemetry:
Data Recording
Microwave repeater sites
BTS base stations
Broadband/spread spectrum radio
VSAT's and gateways
Rural telephony
Two-way radio
Traffic Safety and Control/Transportation Aids:
Message boards
Warning signals
Emergency call boxes
Traffic counters
Intelligent transportation systems
Navigational aids
Lighting
Security:
CCTV and surveillance cameras
Lighting
Perimeter protection
Call boxes
