Single Side CNC Flame Cutting Machine With Cutting Torches , Siemens / Schneider Electrical Parts

FOB Price

Negotiable / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	H-WELDING		Place of Origin	China
Model Number	CNC-CG4500

Delivery Time:15 working days after received your payment
Certification:CE

Stable Single Side CNC Flame Cutting Machine Custom With Cutting Torches With Siemens / Schneider Electrical Part

Specification

Model	Driving type	Rail span(mm)	Effective width(mm)	Cutting thickness(mm)	Vertical range of the cutting torch(mm)
CNC-CG-3000	Single side	3000	2200	6-150(Refer to the performance of the cutting nozzle)	150
CNC-CG-3500	Single side	3500	2700	150
CNC-CG-4000	Single side	4000	3200	150
CNC-CG-5000	Double side	5000	4200	150
CNC-CG-6000	Double side	6000	5200	150
CNC-CG-7000	Double side	7000	6200	150
CNC-CG-8000	Double side	8000	7200	150
CNC-CG-9000	Double side	9000	8200	150
CNC-CG-10000	Double side	10000	9200	150
CNC-CG-11000	Double side	11000	10200	150
CNC-CG-12000	Double side	12000	11200	150
CNC-CG-13000	Double side	13000	12200	150

Description:

Beam rail adopt complete rectangular pipe welded according to trapezoidal basket frame structure and through vibration aging treatment,

With strong anti-deformation and light inertia. Ensure non-deformation after long time using.??

Applications:

Plate cutting for variable shape

Carbon steel

Stainless steel

Competitive Advantage:

Automatic programming nesting software:? Australia Fastcam

Transverse linear rail: TAIWAN HIWIN
