3 Way Line Array Speaker
Negotiable
/ Piece
8 Pieces(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Brand Name | Dimuk | Place of Origin | China | |
| Model Number | Dla1210 |
Product Description
Description
The Dla-1210 Speaker uses advanced divergence shading where all loud-speakers are powered at equal level. Can provide uniform sound coverage from directly beneath itself out to hundreds of feet without complex signal pro-cessing. Vertical coverage for the array is set by varying the splay of the rear of the enclosures, leaving the fronts tight-packed. This configuration produces a continuous, coherent wavefront from the array, projecting extended range, high-resolution sound over its full coverage area.
Quality construction features include, Baltic birch plywood enclosures, heavy-duty steel grilles, Neutrik NL8 connectors, heavy duty bar handles, rear hand-holds, and accessory cast-er pallets.
Applications
This high output touring system is scalable from theaters under 1,000 seats to stadiums. The KF760 is used as the short to long throw element of a KF760 Series line array providing coverage in the range of 70 to 400 feet.
The recommended minimum KF760 array size is four enclosures. For full performance eight enclo-sures are recommended. To extend the low frequency response, The TS-218B make an ideal complement to the Dla Series.
Specifications
Compoents : LF 2x 12-in MF 2x 10-in cone, Radial Phase
Output watts : LF: 2000 @ 8 OHM (2x) MF: 800 @ 8 OHM HF: 300 @ 8OHM
Sensitivity: LF: 96 MF: 108 HF: 113
MAX SPL: LF: 129 MF: 136 HF: 138 ±3 dB
Frequency Range: 80HZ-16KHZ
Cover Range Angle : H 80 vertical coverage determined by array configuration.
Impedance : LF 8 2x8 OHM MF 8 OHM(2@16 OHM each ) HF 8 OHM (2@16 OHM each )
ConnecterS: 2x Neutrik NL8
Dimensions: 368*1143*787mm
Weight : 110KG
