Chain Drive Square Pipe Downspout Roll Forming Equipment 380V 3 Phase 50HZ

Chain Drive 6-12m/min Square Pipe Downspout Roll Forming Machine 380V 3 Phase 50HZ

Square Pipe?Technical Parameter

1. ? Steel Sheet Thickness: 1.5-2mm (depend on requirement )

2. ? Hydraulic power: 5.5Kw

3. ??Transmission way: single chain

4. ? Material of blad: Cr12, quenching treatment

5. ? Capacity of Decoiler: 3 ton passive decoiler

6. ? Forming Speed: 12-15m/min

7. ? Roller Groups: 12-18 stations main roller

8. ? Roller Material: GCr15 grade steel, quenching treatment

9. ? Roller Diameter: 180mm

10. Principal Axis: 45# high grade steel with quenching?treatment

11. Main Motor Power: 7.5 Kw

Square Pipe?Main Components

1. 3 ton passive?decoiler--------------------------------- 1Set

2. Main roll forming machine----------------------------? 1Set

3. Fly saw cutting------------------------------------------- ?1Set

4. Cooling system------------------------------------------ ?1Set

5. Finished products tabel--------------------------------- 2Set

6. PLC control system-------------------------------------- 1Set

7. Straighten device----------------------------------------- 1Set

8. Feeding guiding------------------------------------------- 1Set

9. Levelling device------------------------------------------- ?1Set

Working Flow of?Square Pipe

Decoiler ----?Feeding --- Levelling --- Cutting --- Roll forming --- Fly saw cutting --- Run out table

Profiles of Square Pipe

Company Introduction

??Wuxi Suhang Machinery manufacturing Co., Ltd. is a comprehensive enterprise integrating production, sales and services. We are mainly engaged in providing machineries and equipment.?Owing to a professional teamwork, we are experienced in manufacturing, import and export, customers\' design, installation and test, technical solution and after-sale services. We have shipped out our machines to more than 50 countries, and keep good business relationships with a large amount of worthy customers, contributing to our great business records and reputation.
