Galvanized Steel L Racking Roll Forming Machine 220V 60HZ Three Phase
Negotiable
/ Set
1 Set(Min.Order)
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
SP-CPU-2 PU Continuous PU Sandwich Panel Production Line 6m/min
-
Vally Gutter Safty Cover Downspout Roll Forming Machine Manual Decoiler Hydraulic Cutting
-
Water Vally Gutter Safty Cover Downspout Roll Forming Machine 3 Ton Passive Decoiler
-
Portable Cold Roll Forming Equipment Rainwater Downpipe 16 Stages Post Cutting
-
Gcr15 Steel Rack Roll Forming Machine , Upright Roll Forming Making Machinery
-
100 Meters Per Min Heavy Duty Roll Forming Equipment for Round and Square Tube Mill
Product Details
| Brand Name | Suhang | Place of Origin | China | |
| Model Number | RF-ST |
Product Description
Certification:CE, SGS, ISO
Material Galvanized steel Thickness1.0~2.0mm L Racking Roll Forming Machine Speed 5-12m/min?
1. Technical Parameter
Running?material:?Galvanized?steel?Thickness?–?1.0~2.0mm Forming?speed:??5-12m/min Forming?steps:?9?steps Roller?material: Gcr15 Material?of?principal?axis:?45# steel? Sprocket?wheel:?45?steel?high-frequencies?quench;?distance?25.4.?Quantity:?13pcs? Motor?power:?5.5?KW Cut-off?system:?Adopts?hydraulic?pressure?drive,?cut?off?after?forming. Hydraulic?system?electrical?machinery?power:?3KW Hydraulic?system?pressure:?10Mpa PLC?Control?system:?Brand?of?Siemens?Encoder?is?Japanese?Omron?brand;?the?Inverter?is?Siemens ?brand Overall?Dimension?of?the?main?forming?machine:4000mmX700mmX900mm? Total?weight:??3?ton?approximately Un-coiler:??3?Ton?capacity?of?manual?un-coiler the?punching?press?machine?for?the?holes? Power?supply:?220V?60HZ,?3?phase2. Working Flow
Un-coiler?------?Feeding?device?---Punching?---?Roll?forming?-----?PLC?control?---?Hydraulic?cutting----?
Run?out?table
3. Machine Components
| 3 ton passive decoiler | 1 set |
| servo feeding? | 1 set |
| punching press machine? | 1 set |
| Main roll forming machine? | 1 set |
| PLC control box | 1 unit |
| Hydraulic station | 1 unit? |
| Out table | 2 Units |
4. Profile?
4. Machine Photo
