Fit Up And Assembly Pipe Welding Rotator , Manual Adjustable Welding Turning Roller HGK40
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
ARC MIG TIG Column And Boom Welding Manipulator , Column Boom Welding Machine
-
High Efficient Automatic Welding Column and Boom Manipulator Equipment for Pipe Weld
-
Cylinder Pipe Seam Welding Manipulator Column and Boom for Welding Working Station
-
Middle Duty 5 * 5m Welding Column and Boom For Steel Pipe / Tank Movable Welding
-
Petroleum Industry Welding Column and Boom Full-Automatic for Pipe Rotation Welding Station
-
Motorized Movable Column and Boom Welding Manipulators 6 * 6m For SAW Welding
Product Details
| Brand Name | H-WELDING | Place of Origin | China | |
| Model Number | CHGK40 |
Product Description
Certification:CE
Manual Adjust Welding Turning Roller HGK40 Fit Up And Assembly For Shell
Specifications:
|
Manual Adjust Welding Turning Roller HGK40 Fit Up And Assembly For Shell Model |
CHGK-2 |
CHGK-5 |
CHGK-10 |
CHGK-20 |
CHGK-40 |
CHGK-60 |
||
|
Max. loading (T) |
2 |
5 |
10 |
20 |
40 |
60 |
||
|
Vessel diameter (mm) |
150-2000 |
250-2300 |
320-2800 |
500-3500 |
600-4200 |
750-4500 |
||
|
PU roller dia.&width(mm) |
200*80 |
250*120 |
300*140 |
350*150 |
400*180 |
45*180*2 |
||
|
Metal roller dia.&width(mm) |
Option |
|||||||
|
Linear speed mm/min |
100-1000 |
|||||||
|
Speed control way |
VFD (stepless variable frequency speed control) |
|||||||
|
Motor power (KW) |
2*0.18 |
2*0.37 |
2*0.55 |
2*1.1 |
2*1.5 |
2*2.2 |
||
|
Roller center distance adjust way |
Lead screw adjustable |
|||||||
|
One set inc. |
One power and one idle |
|||||||
| ? | ? | ? | ? | ? | ? | ? | ? | ? |
Note: For 2-100T roller is steel and rubber combination roller.For 100-500T roller is made of whole steel roller or imported rubber.
Description:
HGK-10 welding rotator by lead screw Excellent speed reducing driven organ Frequency conversion stepless speed regulationApplications:
Use manual screw or bolt stepping for regulation, Large ton adopts prepared screw to adjust central distance of roller, To adjust to the change of diameter of work piece.Competitive Advantage:
We also can design the customize various types of the welding rotator in accordance with the customers requirement.
