Customized Half Square Gutter Downspout Roll Forming Machine Panasonic PLC Control System

Customized Half Square Gutter 0.4-0.7mm Downspout Roll Forming Machine Panasonic PLC Control System

Half Square Gutter?Technical Parameter

1. ? Steel Sheet Thickness: 0.4-0.8mm (depend on requirement )

2. ? Hydraulic power: 4Kw

3. ??Transmission way: single chain

4. ? Material of blad: Cr12, quenching treatment

5. ? Capacity of Decoiler: 3 ton passive decoiler

6. ? Forming Speed: 10-20m/min

7. ? Roller Groups: 12-18 stations main roller

8. ? Roller Material: GCr15 grade steel, quenching treatment

9. ? Roller Diameter: 180mm

10. Principal Axis: 45# high grade steel with quenching?treatment

11. Main Motor Power: 7.5 Kw

Half Square Gutter?Main Components

1. 3 ton passive?decoiler-------------------------------- 1Set

2. Main roll forming machine----------------------------? 1Set

2. Hydraulic station----------------------------------------- ?1Set

3. Cutting device-------------------------------------------- ?1Set

4. Finished products tabel--------------------------------- 2Set

5. PLC control system-------------------------------------- 1Set

6. Spare parts------------------------------------------------ 1Set

Working Flow of?Half Square Gutter

Decoiler ----?Feeding --- Levelling--- ?Cutting ---Roll forming---?Run out table

Profiles of Half Square Gutter

Company Introduction

? Wuxi Suhang Machinery manufacturing Co., Ltd. is a comprehensive enterprise integrating production, sales and services. We are mainly engaged in providing machineries and equipment.?Owing to a professional teamwork, we are experienced in manufacturing, import and export, customers\' design, installation and test, technical solution and after-sale services. We have shipped out our machines to more than 50 countries, and keep good business relationships with a large amount of worthy customers, contributing to our great business records and reputation.
