Durable Omega Type Metal Stud Roll Forming Machine / 5.5KW Roll Forming Equipment

Strengthening Used Omega Type Stud / Track Framing Roll Forming Machine

Technical parameter

1. ? Steel Sheet Thickness: 0.4-0.8mm (depend on requirement )

2. ? Hydraulic power: 4Kw

3. ??Transmission way: chain

4. ? Chain: 1 inch single chain

5. ? Capacity of Decoiler: 3 Ton passive decoiler

6. ? Forming Speed: 10-12m/min

7. ? Roller Groups: about 13?stes main roller

8. ? Roller Material: 45# high grade steel with finish machining treatment, by high frequency quenched HRC58-62

9. ? Roller Diameter: 100mm

10. Principal Axis: 45# high grade steel with quenching?treatment

11. Main Motor Power: 5.5 Kw

Applications

Metal stud and track, steel stud and track, c stud, u runner, u track, furring channel, roof ceiling batten, roof truss, c truss, light weight steel truss...

Furring Channel?Working Flow

De-coiler—→feedingwithguide—→main roll forming machine—→cutting—→ run out table

Furring Channel?Profile Drawing

Main Components

1. Decoiler---------------------------------------------------- 1Set

2. Main roll forming machine----------------------------? 1Set

3. Hydraulic station----------------------------------------- ?1Set

4. Cutting device-------------------------------------------- ?1Set

5. Finished products tabel--------------------------------- 2Set

6. PLC control system-------------------------------------- 1Set

Advantage for our PU roller shutter

1. Reasonable Price

2. High Quality

3. 12 Months Warranty

4. More Than 10 Years Experience

5. Durable

6. Reliable

Rolling Shutter Door Forming Machine Pictures
