Home > Products > Steel Bead Wire > Industrial Steel Bead Wire 3*0.22/9*0.20 HT Normal Tensile Steel Tire Cord For TBR Use
Industrial Steel Bead Wire 3*0.22/9*0.20 HT Normal Tensile Steel Tire Cord For TBR Use
- T/T L/C D/P D/A
- 7 days
You May Like
-
HighTensileBrass Plated Steel Wire TBR Radial Tire Steel Cord 3+9*0.22W HT
-
Steel GN125 GS125 Speedometer gearbox Suzuki Motorcycle Parts arithmometer
-
Electro Silver Galvanized Steel Iron Wire Bwg24 High Carbon Steel Wire
-
Galvanized steel Crane Wire Rope
-
Armored Fiber Optic Assemblies Outdoor Type LC SM High Crush Resistance
-
Copper Coated Radial Tyre Steel Cord 3*7*0.20 HE HighTensile Conveyor Belt Steel Cord
Product Details
Brand Name | JUNMA | Place of Origin | China | |
Model Number | 3*0.22/9*0.20 HT |
Product Description
Certification:TS16949
3*0.22/9*0.20 HT ?Golden ?Normal Tensile Steel Tire Cord For Tbr Use?
Quick Detail:
Name |
Steel Cord for Radial Tires?? |
Brand Name |
?JUNMA |
Color |
Golden |
Feature |
?High Breaking Strength |
Linear Density |
3.17g/mm |
Certificate |
TS16949 |
Specifications: ?Steel Cord for Radial Tires
STRUCTURE |
DIA.?????????????? (MM) |
LAY LENGTH (MM) |
LAY DIRECTION |
MIN.B.S??????????????? (N) |
LINEAR DENSITY (G/M) |
ADHESION (N) |
3+9+15*0.175W NT |
1.34 |
5/10/16/3.5 |
SSZS |
1670 |
5.42 |
≥1100 |
3+9+15*0.22W NT |
1.62 |
6.3/12.5/18/3.5 |
SSZS |
2550 |
8.5 |
≥1300 |
3+9+15*0.225 HT |
1.39 |
6.3/12.5/18 |
ZZZ |
3120 |
8.63 |
≥1370 |
0.25+6+12*0.225 HT |
1.10 |
8/16 |
ZZ |
2225 |
6.05 |
≥500 |
0.22+6+12*0.20 HT |
1.02 |
6.3/12.5 |
ZZ |
1775 |
4.86 |
≥400 |
0.22+6+12*0.20 ST |
1.02 |
6.3/12.5 |
ZZ |
1950 |
4.86 |
≥400 |
3+8+13*0.18W HT |
1.34 |
5/10/16/3.5 |
SSZS |
1670 |
5.1 |
≥570 |
3/8+13*0.22W HT |
1.56 |
12/12/18/5 |
SSZS |
2548 |
7.45 |
≥1176 |
3+8+13*0.22W HT |
1.56 |
6/12/18/5 |
SSZS |
2548 |
7.45 |
≥1176 |
2+7*0.22 HT |
0.83 |
6.3/12.5 |
SS |
1060 |
2.74 |
≥400 |
2+7*0.25 HT |
0.94 |
7/14 |
SS |
1275 |
3.53 |
≥450 |
2+7*0.37 HT |
1.42 |
10/20 |
SS |
3010 |
7.64 |
≥550 |
3*0.24/9*0.225 CC/HT |
0.94 |
14/14 |
SS |
1445 |
3.94 |
≥380 |
3*0.24/9*0.225W HT |
1.17 |
12.5/12.5/5 |
SSZ |
1451 |
4.09 |
≥1000 |
3*0.22/9*0.20 HT |
0.88 |
12.5 |
SS |
1220 |
3.17 |
≥850 |
3+8*0.33 HT |
1.37 |
10/18 |
SS |
