Home > Products > fusion splicer > FTTx Fusion Splicer DVP-600
FTTx Fusion Splicer DVP-600
- 0 Case / Cases per Month
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Place of Origin | China | |
| Model Number | DVP-600 |
Product Description
Features:
2.5 inch LCD color display
Small volume, light weight
Suitable for science research
Multiple language options
User programmable
8 Sec. splice time, 40 Sec. tube-heat time
Auto check fiber end face
Auto calibrate parameter
Technical parameters:
|
Applicable fibers |
SM, MM, DS, NZ-DS(G655), EDF |
|
Fiber cleaved length |
8-22mm |
|
Average splice loss |
0.1dB(SM),0.08dB(MM),0.07dB(DS),0.07dB(NZDS) |
|
Return loss |
≥60dB |
|
Tension test |
2.0N(200gf)(Standard) |
|
Protection sleeve length |
20mm, 40mm, 60mm |
|
Splice Program |
User can set the best program according to the environment conditions |
|
Environment conditions: |
-25~+50℃ (operation temperature), 0~95%RH (humidity), 0~4000m (altitude) |
|
Storage environment |
-40~ +80℃ (temperature) , 0~95%RH (humidity) |
|
Power supply |
Internal battery: 12V, 6Ah, up to 60 times of continuous splices and heats |
|
Dimensions/Weight |
130(D)×135(W)×135(H)mm/2.0kg |
