DVP-321 OTDR
Negotiable
/ Case
1 Case(Min.Order)
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Place of Origin | China | |
| Model Number | OTDR |
Product Description
One key-press measurement and one key-press storage
Shortcut key design, one key-press setup
Smart portable OTDR, large colorized LCD screen
Firm, durable, shock-proof, moisture-proof
Large storage capacity, maximum store up to 800 measurement files
Built-lithium batteries, more than 10 hours working hours
Support USB and network interface, more convenient to manage files
| Model | Wavelength(nm) | Dynamic Range(dB) | Event Dead Zone (m) | Attenuation Dead Zone (m) |
| DVP321 | 1310±20/1550±20 | 31/29 | <3m | <25m |
General Parameters
| Distance range(Km) | 5m -160km |
| Pulse width(ns) | 5ns-10μs |
| Measurement time | user-defined(smart link) with real-time measurement function |
| Distance accuracy(m) | ±( 0.5m ±0.001%×range + sampling resolution) |
| Attenuation accuracy | ±0.01dB/dB |
| Loss limit(dB) | 0.01dB |
| Loss resolution(dB) | 0.001dB |
| Sampling resolution(m) | 0.1m |
| Sampling points | 64000 |
| Data storage | 800 item |
Other Indicators
| LCD type | 4.0 inch TFT colorized LCD |
| Laser adapter | FC/PC SC/PC |
| Interface | USB , RJ45 |
| Battery | built-in rechargeable Li-ion battery charging time <4 hours working time >10 hours |
| Power | AC/DC adapter input AC90-240V ±10 %output DC18V |
| Operating temperature | 0-40 |
| storage temperature | -10-50 |
| relative humidity | <80% |
| weight | <1.5Kg |
| dimensions (mm) | 247×130×67mm |
Standard Configuration
| Standard Configuration | Amount |
| OTDR | 1 |
| AC-DC power adapter/charger | 1 |
| User Manual | 1 |
| Bag | 1 |
| FC adapter | 1 |
| SC adapter | 1 |
| CD | 1 |
