Stainless Steel Large Rotating Single Liquid Dispensing Valve For Epoxy VSD-040

VSD-040 single liquid dispensing valve for epoxy dispenisng

Specifications:

Description:

1) The diaphragm uses the newest technology and the part of contact liquid is the anti-corrosive material
2) Liquid is neat and without dripping
3) The body of valves is made of aluminum alloy anode carburizing
4) It is suitable in the middle and high viscosity liquid

Large rotating surface design, easy to remove. Flexible PP needle good for complicated working place, prevent scratching, make glue dripping easy. Unique The needle design to ensure the accuracy of the needle length. No flash precision stainless steel tip, ensure continuous glue effect.

This section of the glue dispensing valve is small, shutting down form using sealed plastic thimble, can instantly stop stream. For? low viscosity fluids, such as grease, silicone, epoxy, UV, paint and other liquids. Commonly used in the 0.01-5g each dispensing process. Can be used with solenoid valve or dispensing controller automatic control operation

It\'s favorable for dispensing lubricant liquids and the application pressure of the material is possible up to 60kgf/. Applicable materials: epoxy , resin, glue. Application cases: Video Deck(Grease Multi spread), CD ROM deck(Oil spread), various kinds of gear equipments, Grease spread?

Applications:

1 .Fit?for?large?glue?outflow?with?the?big?orifice,the?discharge?rate?can?be?fine?adjusted?.

2. The?part?of?connecting?liquid?use?anticorrosive?material.

3. Functions?of?preventing?liquid?and?suck-back easy?to?install.

4 .Application?to?single-component?glue,?two-components?epoxy?resin, polyurethane, silicone, etc.
