Home > Products > CCD Dome Camera > 27x 5.0 inch Double housing CCD Dome Camera , 360Continuously Rotation
27x 5.0 inch Double housing CCD Dome Camera , 360Continuously Rotation
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Brand Name | Yuntai | Place of Origin | China | |
| Model Number | HB-105PEAW-CNB27B |
Product Description
Certification:CE , RoHS , OEM
2.Multiple brands camera protocols
3.Provide 128 presets
4.27x cctv dome camera
High speed cctv dome camera?Features:
Die-cast high strength alloy, metal construction in housing, 5.5- inch. Double housing, Built-in fan and heater. Built-in decoder consists of multiple communications protocols and baud rate. Multiple brands camera protocols. English OSD menu function, and 4 self studying tracks, 60s/track, total is 240s. 360° continuously rotation, rotation rate 300°/s. Provide 128 preset positions. 4 programmable tracks,2 scanning tracks,12 private zones cover Auto start tracking function Coordinate displayed function. High speed for wide-angle, low speed for far distance Built-in surge and lighting strike protective equipment. Memory information at power-off. Alarm linkage function (selection)Specification:
|
Image sensor |
1/4\" CCD |
|
Active pixels |
752(H)×582(V) |
|
Synchronization |
Internal/Extrinsic |
|
Video output |
VBS 1.0Vp-p/75 ohms |
|
White balance |
Auto/Manual |
|
Scanning frequency |
15.625KHz(H) 50Hz(V) |
|
Horizontal resolution |
480TVL |
|
S/N ratio |
≥48dB |
|
Electronic shutter |
1/50~1/10,000s |
|
Min illumination |
0.1Lux |
|
Focal length |
F=3.6~97.2mm 27x |
|
Focal & Iris |
Auto/Manual |
|
Pan speed |
0.1°~300°/s |
|
Tilt speed |
0.1°~130°/s |
|
Pan range |
360° Continuously |
|
Tilt range |
90°(180° auto overturn) |
|
Preset |
128(max) |
|
Communication |
Multi-protocol, RS485 |
|
Relative humidity |
90%without agglomeration |
|
Work temperature |
-35°C~55°C |
|
Power supply |
AC24V |
