Shanghai Golden Impact Crushers Saler

FOB Price

US$ 30000 - 30000 / Set

1 Set(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	golden		Place of Origin	China
Model Number	Impact Crusher

Product Description

shanghai golden Impact crushers saler

Impact crusher Applicability

Impact crusher is used in crush kinds of materials such as fineness below 500mm,and the pressure resistance around 360mpa.It has features of big crushing rate,efficient crushing, easy maintenance and the final production is cubic.It is the deal mining equipment of high road and water conservance.The impact crusher is widely used in high road, water conservance and building linestone mining and so on,with perfect features and good factioning.even in moorstone,limestone and cabble with better suitble features.

Impact crusher Features and benefites

Impact plate with a special shape,wear- resistant liner plate,specially in hard mining crush,high efficicency and reduction ratio.the final production is cubic shape,required adjustment the output feed fineness,simplifying the process of the crushing.

Impact crusher Structure features

1.Big output opening,high crushing cavity,suitble in high hardness,big pieses and less power
2.The gap in the impact and the hammer plate can be adjusted,efficient control the output feed fineness, the final production has good shape
3.Tight strucure, good equipment rigidity,big rotational inertia
4.High hammer plate,big impact resistance and wear resistance.
5.No-board conection,easy maintenance and rellable operation.
6.Full-featured,high-efficiency,small dentel wear and high overall efficiency.

Impact crusher Technical parameters

Model	Roller size mm	Output size mm×mm	Max feed side length mm	Pressing power t/h	Motor power kw	Weight t	Overall dimension L×W×H mm
PF-1007	φ1000×700	400×700	300	37-45	55	9.5	2400×1558×2660
PF-1010	φ1000×1050	400×1080	350	50-80	75	12.2	2400×2250×2660
PF-1210	φ1250×1050	400×1080	350	70-120	110	14.1	2690×2338×2890
PF-1214	φ1250×1400	400×1080	350	80-180	132	18.6	2690×2688×2890
PF-1315	φ1300×1500	860×1520	500	150-220	200	24	2860×2800×3050
PF-1316	φ1320×1600	1690×860	500	170-280	200	25.5	3096×2850×3050
