Semi-Automatic CNC Angle Punching & Marking Machine

FOB Price

Negotiable / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Sunrise		Place of Origin	China
Model Number	TAP16A

Applicable industry:

The machine is the special equipment used for angle steel marking,punching and half-automatic production in the field of power and telecommunication.

Product feature:

1.Adopt CNC technology, servo motor infeeding, with high efficiency, stable workpiece precision.

2.Key hydraulic,pneumatic and electric parts all imported.

3.Easy programming and can directly use the program data made by lofting software.

4.Computer with Chinese/English interface, easy operation, and can display the drawing of workpiece.

5.Only need to input size of workpiece, diameter of holes, stadia and quantity of workpiece when edit program, or use CAD/CAM direct conversion.

6.Two gradient unloading units are used for preventing angles from being lifted by punching head.

7.With self-diagnosis failures function.

Product Basic Parameter:

Model	TAP16A
Functions	Punching&Marking
Angles size (mm)	L40×40×3~L160×160×12
Angles size (mm)	L40×40×3~L160×160×12
Max. diameter of punching(mm)	Φ26
Punches(piece)	2
Stadia of punching(mm)	20~110 (Stepless)
Min. end distance of punching(mm)	25
Nominal force of punching	800
Nominal force of punching(kN)	1000
No.of character group (piece)	1
No.of character in each side(piece)	12
Character size (mm)	14x10x19 By customers’request
CNC axes (piece)	2
Positioning speed of servo motor(m/min)	20
Programming mode	Input by keyboard, RS232 interface, floppy disk and USB interface
Precision	Accordance with GB2694
Overall dimensions L×W×H(m)	18.9×2.3×2.6
Weight of machine(kg)	Approx. 10000
