FRTB-LD400 Paper tube Labeling Machine (Two Side Glue)

1. Scope of Application:
    This machine is suitable for labeling Paper Can, Glass Bottle, Plastic Bottle, Metal Column Container in the industry of Chemical, Pesticides, Foodstuff, Beverage, etc, especially outside wrap-around paper cans.

2. Features:
1)  The machine is suitable for various paper cans labeling in full circular or semi-circular.
2)  The machine is suitable for various can shapes. The operator only adjusts the label size, or changes can shape easily without replacing any parts in few minutes.
3)  The operator only needs to put the container in the machines, and then the machine will feed label, glue label, label on the container automatically.
4)  This machine uses two side glue on the label, and the surface of finished products will not have the appearance of concave-convex and bubble. And the finished label will cling to can tightly in case of crush or glue failure.
5)  This machine adopts melt adhesive to ensure excellent labeling, and it will not appear glue or adhesive failure while wet, low or high temperature. We develop the melt adhesive by ourselves, and it can avoid the excessive glue while using water gel.
6)  Inside of machine has automatic temperature control heater, and also has the protection settings for motor non-starting while glue freezing.
7)      The machine has the automatic counter inside, and it can greatly raise the working efficiency afterwards.
8)  The machine adopts advanced techniques from Japan, and develops a new and unique paper feeding system, in order to make it feed the paper one by one.
9)  The operator can use 6-10mm width Paper label on two sides of paper can. It can save glue amount and reduce production cost.

3. Technical Parameters:
      Speed: 20-40 pcs/ Min.
      Bottle Diameter: 20-ā200
      Label Height: 20-400MM
      Voltage: Three Phase 380 V
      Frequency: 50/60HZ
      Power: 1.3 KW
      Weight: 240 KGS
