Stationary concrete pumps

Brand Name	REALTOP		Place of Origin	China
Model Number	HBT60.13.130RSB

Realtop Heavy Industry is a specialized manufacturer for construction machineries in Hunan province, South China.

trailer mounted concrete pumps is one kind of our mature products. we manufacture seires of models to satisfy the needs of our client.

Now we'd like to recommend one of the hot model which move fast in market:HBT60.13.130RS with diesel engine.

Main oil pump: Germany Rexroth products/Japanese Kawasaki products/Chinese famous brand Liyuan

Diesel engine: Germany Deutz/ Perkins/ Shangdong weifang

Clients could decide the devices equipped according to their requirement of the prices.

Main technical parameter
Models HBT60.13.130RS
Max. Theor. Concrete Output 81m³/h
Concrete Pressure 13mpa
Theor. Max. Horizontal Delivery Distance 1350m
Theor. Max. Vertical Delivery Distance 350m

Main Pump: Original Germany REXROTH

Cylinder Diameter/Rod D /Stroke  125/80/1650mm
Concrete Cylinder Bore /Stroke 200/1650mm

diesel engine German Deutz made in China with licence130kw

Rated Rotating Speed 2200r/m
Hopper Capacity 660L
Hopper Height 1400mm
Oil Tank Capacity 500L
Hydraulic Circuit Form   Opened-circuit
Delivery Valves Style    S-valved
Max. Grain Diameter Pebble:50 mm Crushed Stone:40mm
Out Dimension 6400/2160/2800mm
Total Weight 6300kg
