Home > Products > Environmental Testing Equipment > Digital Chroma Light Meter Illuminometer Temperature Brightness LED Lamp Tester / Color Meter

Digital Chroma Light Meter Illuminometer Temperature Brightness LED Lamp Tester / Color Meter

FOB Price

Negotiable / Kilogram

1 Kilogram(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	SENTRY		Place of Origin	China
Model Number	ST520

Product Description

Delivery Time:3 working days after received your payment
Certification:CE/ROHS/SGS/ISO9001

Chroma Meter Color Meter digital Light Meter SENTRY ST520 illuminometer temperature brightness LED lamps tester

Features

Precision instrument for light luminance and color coordinate

Meet CIE (International Commission on Illumination) photopic spectral response

Color temperature or Correlated color temperature

Custom reference value of color difference mode

Lux or foot-candle unit selection?

Magnetic mount

Tripod socket

Specification

Specifications	?
Receptor	Silicon photocell
Measuring Function	Illuminance: Ev (lx or fcd) Color Coordinate: (x,y), (u\',v\') (CIE 1960) Correlated Color Temperature: CT, Δuv Color Difference:(ΔEv,Δx,Δy), (ΔEv,Δu\',Δv\'), (ΔEv,Δu\'v\'), (One set of reference color)
Measuring Range?	Ev=0~80,000 lx (0~7,432 fcd); CT 99,990K Max.
Accuracy (at 25°C/77°F, 60%RH)	Ev: ±(3%+2 digital) (3,000 lx, standard illuminant A measured) x, y: ±0.02 (100 lx, RGB LED light)
Resolution	Ev: 0~9999 lx: 1 lx, Over 10000 lx: 10 lx; 0.0~999.9 fcd: 0.1 fcd, Over 1000 fcd: 1 fcd; CT: 0~9999 K: 1 K, Over 10000 K: 10 K; x, y: 0.001; u\'v\': 0.001
Response Time	Approx. 1 sec.
Temperature Drift	Ev: ±(5%+2 digital) (3,000 lx, standard illuminant A measured) x, y: ±0.008 (100 lx, RGB LED light)
Humidity Drift	Ev: ±(3%+2 digital) (3,000 lx, standard illuminant A measured) x, y: ±0.005 (100 lx, RGB LED light)
Operation Temperature	0~50°C (32~122°F, <80%RH)
Store Temp.	-10~60°C (14~140°F, <80%RH)
Dimensions	Main Instrument: 140 X 49 X 29mm ( 5.51\" x1.93\"x1.14\") Sensor Probe: 165 X 50 X 36mm ( 6.50\" x1.97\"x1.42\")
Weight	179g (6.31 oz.) without battery
Accessory	9V Battery, Instruction manual, Carrying Case

Applications

Color LED Lighting

Commerical Displays

Film and Television

Projection Halls

Warehouses

Art Galleries

Museums

Schools & Libraries

Theatres

Arenas

Stadiums

Office
