25.4mm 1000M Double Port Tab UP Transformer RJ45 Connector for Internet Set-top Box
- T/T L/C D/P D/A
- 7 days
You May Like
-
Custom Single Port 33.0mm RJ45 Connectors 1000BASE With Transformer
-
Integrated 1000 BASE Tab Up Transformer RJ45 Connectors Plugs for Fiber Optic Transceivers
-
Custom 1 Port Tab Down Transformer RJ45 Connector 10 / 100BASE KRJ-171DNL
-
PBT Black Jack 100 Base RJ45 Connector Integrated With Transformer for Telecommunication
-
Customized RJ45 Transformer 10 / 100BASE With UTP-5 Cable for Net Bridge / Computer
-
10 / 100 Base Integrated RJ45 Connector With Ethernet Transformers for Internet Camera
Product Details
| Brand Name | DGKYD | Place of Origin | China | |
| Model Number | KRJ-2542QNL |
Product Description
Certification:SGS、UL、
25.4mm ?1000M Double Port Tab UP Transformer RJ45 Connector for Internet Set-top Box
25.4mm?1000BASE?1x2?Tab?UP?Transformer?RJ45 ?KRJ-2542QNL
Description:
RJ45?,in?order?to?keep?good?touch?between?gold?finger?and?crystal?head,should?paint?the?gold?on?the?
surface,there?is?6u,15u,30,50u,usually?use?6u,according?to?customer’s?request?and?cost?to?proceed, ?
gold?finger?insert?and?pull?life?should?be?750?times?above
|
1.1?RJ-45?connector?integrated?with?X\'FMR/??Impedance?Resistor/High?Voltage?Capacitor. |
|
|
1.2?Size?same?as?RJ-45?connector?to?save?PCB?board?space. |
|
|
1.3?Design?for?10/100/1000?base?transmission?over??UTP-5?CABLE.? |
|
|
1.4?Operating?temperature?range?is?0℃~70℃. |
Specifications:
.Insertion?Loss?:1-100MHZ?-1.0dBmax
.Rturn?Loss?:??1-30MHZ?-16.0dBmin
???????????????30-60MHZ?-14.0dBmin
???????????????60-80MHZ?-10.0dBmin
.Cross?Talk?:1-30MHZ?-40.0dBmin
??????????????30-60MHZ?-35.0dBmin
??????????????60-80MHZ?-30.0dBmin
.CMR:1-100MHZ?-35.0dBmin
.Hi-Pot:1500V?AC?6S?1mA
.Turn?Ratio?:1CT:1CT±3％
.OCL:350uH＠100KHZ?100Mv?8mA?DC
.Contacts:0.35mm?thick?phos?bronze?plated?with?6u’gold?in?contact?are?
.Housing?Material:PBT?Black
.Operating?temperature?rang?:0℃?to?+70℃
Applications:
Integrated?RJ45?connector?main?used?to?:?
??10/100/1000M?net?card,PCMCIA?net?card,USB?Hub,network?switch,router,fiber?optic?transceivers,optical?
transceiver,IP?phone,?internet?set-top?box,internet?camera,net?bridge,computer,telecommunication,MODEM,
HomePNA,DSL／ADSL?and?so?on.
Competitive?Advantage:
Keyouda?has?various?types?of?appearance?and?many?kinds?of?internal?schematic?products,high?quality,?
customer?firstly?,100%?test,?0?defect,?short?lead?time?are?our?best?advantages
