Sell Cut to Length Line

Place of Origin	China

Model No.:ZTC-8X2000
Product Origin:China
Brand Name:Reliantt
Price Terms:
Payment Terms:
Certification:
Description:A.Using range of Line 1)Coil Material: hot rolled Coil(Q235A).cold rolled coil 2)Coil Thickness: 3-8mm 3)Coil Width: 1200-2000mm 4)Inner Dia. Of Coil: 610mm, 750mm 5)Max. Weight of Coil: 30 tons B.Main Technical Data 1)Straighten Speed: 5-20m/min 2)No. of rollers for straightening: 11 rollers 3)Dia. Of roller for straightening: 170mm 4)Error for cut to length: +/-3mm(as per cut for 6mm X 2000mm sheet) 5)Range of cut to length: 500-9000mm 6)Motor of straightening: 55KW 7)Total Power of Line: Appro.150KW 8)Space of Line: 220000mm X 7000mm 9)Weight of Line: 72000KG C.Component of Line 1)Coil Lifter 1pc 2)Hydraulic Decoiler 1 set 3)Guide Slide with Pinch roll 1 set 4)Conveyor 1pc 5)Sid Guide 1pc 6)11 rollers type Straightener 1pc 5 Up rollers + 6 down rollers 7)Measure roll 1pc 8)Hydraulic Shearing Machine 1pc 9)Conveyor with Pinch roll 1 set 10)Pneumatic Stacker 1 set 11) Hydraulic System 1 set 12) PLC Electric System 1 set
