Lowest price Multiplexer
Negotiable
/ Set
1 Set(Min.Order)
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Brand Name | JieXun | Place of Origin | China | |
| Model Number | JXDH6102 |
Product Description
JXDH-6102 multiplexer is a digital broadcasting TV system TS stream re-multiplexer
Outline
JXDH-6102 multiplexer is a digital broadcasting TV system TS stream re-multiplexer. JXDH-6102 multiplexer combines several single-programs or multiple-programs, which are compressed, coded, and multiplexed according to customer request by head-end, into single transport stream. Besides, it is also able to interpolate EPG (Electronic Program Guide), CA (Conditional Access) and digital broadcasting etc. Maximally, it can synchronal multiplex 8 route input code streams, and support ASI interface. The code rate of input code stream is maximally up to 270Mbps, while code rate of four separate outputs code stream is maximally up to 108Mbps. Through auxiliary data input channel, Its dimension is standard 1U case. By watching the LCD display on the front panel, user can finish the setting of auto-running of this device.
Features
◆ Complying ISO13818 standard.
◆ Support MPEG-2 transport stream re-multiplexing.
◆ Multiplexing SPTS and MPTS code stream.
◆ SDT table reflection
◆ Able to connect independent scrambler for scrambling to specified program or service.
◆ Generating SPI/SI information
◆ Support PCR adjusting and PID re-reflection
◆ Able to extract PSI/SI information from any route of SPTS/MTPS inputs
◆ Able to interpolate data, and re-multiplex and transport any kind of data
◆ Support statistic multiplex
◆ Support the cascading connection of several equipments.
◆ Central net administration, remote updating and maintenance
◆ LCD display, flexible and user-friendly in operation
◆ High reliability design, stable in running
◆ Alarm display
◆ Support network upgrade
◆ Two groups ( four routes) separate ouput channel,support two separate outputs.
Specifications
|
Input Interface
|
ASI
|
8Routes Standard ASI Interfaces
|
|
|
Maximum 270Mbps per route
|
|||
|
Re-multiplexing
|
Re-multiplexing MPEG-2 stream
|
||
|
PID re-reflection
|
|||
|
PCR reset
|
|||
|
Automatically generating PSI/SI table
|
|||
|
OutputInterface
|
ASI
|
4 routes(2 gyoups separate output)
|
|
|
PID
|
Output PID range
|
0000-1FFFF
|
|
|
Random PID transparenttransport
|
Random PID transparent transport possible
|
||
|
Max PID number
for each input |
256
|
||
|
Data input
|
Packet Format
|
Auto identification,188/204byte,encoding
|
|
|
Network Management Interface
|
Ethernet Interface
|
10/100M
|
|
|
RS232 Interface
|
Software Upgrade
|
||
|
Miscellaneous
|
Dimension
|
44mmx482mmx410mm
|
|
|
Temperature
|
0-45℃ (Operating) ; -20-80℃ (Storage)
|
||
|
Power
|
220VAC±10%,50Hz,25W
|
||
Warm tips:
Specification and picture are for reference only, the actual item is the standard,welcome to consult.
