Home > Products > Stone Engraving Machine > JK-1326 CNC Engraving Machine for Stone

JK-1326 CNC Engraving Machine for Stone

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Jingke		Place of Origin	China
Model Number	JK-1326

JK-1326CNC Engraving Machine for Stone:

Machine features for JK-1326 CNC Engraving Machine for Stone:

Particular style, competent for elaborate engraving and cutting.

The lathe bed is wholly cast steel to ensure high stability. Three axes all adopt linear square rail.

Be compatible with type 3, Artcut, Artcam software.

Memory to ensure the processing point when the blade is broken or postpone stitution. Specific saving mode of different points.

Technical parameter:

Model	JK-1326S
Machine body	Cast steel
Work dimensions	1300 x 2600 x 200mm
Body dimensions	1600 x 3200 x 1600mm
X/Y/Z movement	Rack and pion drive
Guide	Linear square rail/Taiwan
Working area	1300*2600mm
Diameter for rotator	300mm
Z-axis working area	200mm
Max. Feeding height	200mm
Cut thickness of material	40mm
Max. Speed	20m/min
Working speed	10m/min
Mechanical precision	0.01mm
Software	Artcam, Artcut, Type3 software
Power source	AC 380/50-60Hz,2-phase
Driver type	stepper motor
Spindle	3KW variable speed, water-cooled
Spindle speed	0 - 24,000rpm
Blade diameter	ER20-12.7mm,6mm,3.175mm
Control system	DSP(USB interface)
Command	HPGL,G code, u00, mmg, plt
