Home > Products > Stone Engraving Machine > JK-1212 Stone Engraving Machine

JK-1212 Stone Engraving Machine

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Jingke		Place of Origin	China
Model Number	JK-1212

JK-1212 Stone Engraving Machine:

Usage: can be used to engrave various materials.

Machine features of JK-1212 Stone Engraving Machine:

Particular style, competent for elaborate engraving and cutting.

2.2KW water-cooled spindle motor.

The lathe bed is wholly cast with iron to ensure high stability. Three axes all adopt linear square
rail.

Be compatible with type 3, Artcut, Artcam software.

Memory to ensure the processing point when the blade is broken or postpone situation.
Specific saving mode of different points.

Parameter:

MODLE	JK-1212
Work dimensions	1200 x 1200 x 80mm
Body dimensions	1500 x 1550 x 1500mm
Z-axis working area	80mm
Max. Feeding height	120mm or bigger
Cut thickness of material	40mm
Max. Speed	6000mm/min
Working speed	0 - 4000mm/min
Mechanical precision	0.01mm
Software	Artcam, Artcut, Type3 software
Max. Power consumption	1800W
Power source	AC 220/50Hz
Driver type	stepper motor
Spindle	2.2KW variable speed, water-cooled
Spindle speed	0 - 24,000rpm
Blade diameter	1 - 6mm
Control system	NCSTUDIO
Command	HPGL,G code, u00, mmg, plt
N.W.	450KG.
G.W.	500KG.
