Anti - Rust Roller Tile Roll Forming Machine , Sheet Metal Rolling Machine

FOB Price

US$ 10000 - 50000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	bluesteel		Place of Origin	China
Model Number	bl

Delivery Time:45days
Certification:ce
Factory Direct Sale China Style Classical Color Steel Step/Glazed Step Tile Roof Panel Roll Forming Machine

Technical data of?metal roof tile roll forming machine

Suitable material	?color steel sheet;0.3-0.7mm,
Working speed	about10-25m/min
stress	235MPa,345MPa,550MPa.
Power?	Main motor power: 5.5 Kw(Depend on final design)
Hydraulic station power: 4Kw(Depend on final design)
Material of forming rollers	No.45 steel, plated with chrome on surface.
Material of cutter,pressing die	Cr12 mould steel with quench treatment, HRC58-60
Material of shaft	High quality 45# steel,?Roller grinder milling.
Shaft diameter	72mm
Controlling system	Mitsubishi PLC & converter
Total weight of machine	About 9500KGS
Machine’s size	about 18m×1.8m× 1.5m (Depend on final design)

Layout drawing of machine

Our ?Roll Forming Machine’s advantages

1.?Anti-rust roller:?CNC machine tooled, Plated with 0.05mm hard chrome .to protect surface shiniing and strong

2.?Heat treatment:?Heat treatment for cutting frame to remove the steel stress, to avoid deformation.and hardness 60 degree.

3.?Cutter blade:?Cr12 mould steel with quenched treatment, long life time.

4.?High precision:?shafts for rollers are tooled by grinding machine. Rollers are CNC processed to ensure precision performance.

5 .automatic PLC?:?introduced Mitsubishi PLC with touch screen ,inverter,transformer.

6.?powerful driving system: ??big inch train,or gear box driving system.

6.?Excellent services:?Technician can be sent to your factory to install the machine and train your workers. Lifttime services for our machines.?

Product:

Application

We can also customize the products according to customer \' s?requirements
