Home > Products > Stage LED Screens > High Brightness Curve P6.25mm Waterproof Stage Background Led Screen Outdoor 15 Degree

High Brightness Curve P6.25mm Waterproof Stage Background Led Screen Outdoor 15 Degree

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	3Cinno		Place of Origin	China
Model Number	A1-o6

Delivery Time:25~30 working days after received your payment
Certification:CE/ROHS/FCC/SGS

Outdoor P6.25mm Stage LED Waterproof Screens ±15 Degree Curve and High Brightness

Feature:

1,?High brightness ?High brightness?suitable for outdoor application

2.?Curve: ? ? ? ? ? ? ? Curve screen is made with?the angle adjustor (-15°~+15°)

3. 500*500mm: ? ? ?Easy to calculate and assemble any size?screen with integer dimensions.?

4.?Fast:: ? ? ? ? ? ? ? ? Fast?installation, dismantling,?and maintenance, save labour and time cost.

5. Ultra-thin: ? ? ? ? 70mm thickness make screen very slim and only require narrow space to install it.

6.?Lightweight: ? ? With aluminium materials,?each panel is only 7.5kg,?greatly save transportation and labour cost.?

Specification:

Aluminium 500*500 outdoor	Unit	A1-o6
OPTICAL	Pixel pitch	mm	6.25
Pixel configuration	﹣	3535 3-in-1 SMD
Viewing angle(H/V)	degree	140/140
Resolution per tile	pixels	80×80
Brightness	cd/㎡	5500
ELECTRONICS	Refresh rate	Hz	2000
Processing	bit/color	16
Colors	trillion	28.1
Operating power	VAC,Hz	110-240,50/60
Power consumption(max/ave)	W/sqm	750/250
Operating temperature	℃	﹣20 ~50?
Operating humidity	RH	10%~90%
MECHANICAL	Size(W×H×D)?	mm/tile	500×500×70
Frame material	?	Aluminium extrusion
Weight	kg/tile	7.5
Weight	lbs	17
Serviceability	﹣	Rear
Installation	﹣	Stacking/Hanging
Curve	degree	Available, ±15°
Serviceability	﹣	Rear
IP rating	﹣	IP65 Front/IP54 Back
ACCESSORIES	Control System	﹣	Nova
Source compatibility with VP	﹣	CVBS,YUV, DVI,VGA,S-Video,HDMI,SDI,HDSDI,etc.
Cable connectors brand	?	Neutrik / Seetronic
Signal cable		CAT5e:<100m / Single-mode fiber:<10KM
Hanging beam	?	Steel,? 0.5m / 1m length
Package		Flight case, 10 tiles in 1 case

Application:

Outdoor stage, Outdoor?events, TV studio&Film, Sports, etc.

System diagram:
