Product Details
Brand Name | Noble | Place of Origin | China | |
Model Number | NBDJS513-RYG |
Product Description
Certification:CE/ROHS/ISO9001
Road Warning Traffic Light Countdown Timer 100V - 277V IP54 , Turn Traffic Lights Green
1.?Features
? ? ? ?1) This signal is specially designed to increase the safety of car driver, by showing number of ? ? ? ? ? ? ? ? ? ? ? ? ? ?seconds left to change signals from red light to green light to yellow signal or from green signal to ? ? ? ? ? ? ? ?yellow signal to red signal to assist drivers to determine if he should continue driving or should slow ? ? ? ? ? ? down to wait for light changed.
? ? ? ?2) When Green Vehicle Signal is on, the Green Digits will be shown with count down digits, to show the ? ? ? ? ? ? number of seconds left before the Green Light is changed to be Yellow.
? ? ? ?3) When Yellow Vehicle Signal is on, the Yellow Digits will be shown with count down digits, to show the ? ? ? ? ? ?number of seconds left before the Yellow Light is changed to be Red.
? ? ? ?4) When Red Vehicle Signal is on, the Red Digits will be shown with count down digits, to show the ? ? ? ? ? ? ? ? ? number of seconds the car driver needs to wait before the Red Light is changed into Green.
? ? ? 5) The maximum number of two digits is 99 seconds. If the countdown time is set exceeding 99 ? ? ? ? ? ? ? ? ? ? ? ?seconds, the signal will not show the digit until it counts 99 seconds.
?2.?Specifications
Product Name |
Traffic Countdown Timer |
Size |
800*600*70 |
Color |
Green+Yellow+Red |
Wavelength |
625±5 ?590±5 ?505±2 |
Power consumption(W) |
20 |
Housing material |
Cold steel |
Voltage (V) |
12-24V 100-277V |
Luminance |
>4000cd |
Operating temperature |
-30--+70 |
Control system |
Microprocessor |
Display type |
Two digits |
IP rating |
IP54 |
Guaranty |
2 years |
Max Second |
99 seconds |
Profile | Square |
LEDs | R:490s Y:210s G:336s |
Package |
Carton box:Well-packed with K carton+ EPE? |
4.?Package
Model |
Carton?size ? ? ? ?(mm) |
? ?QTY (Set) |
GW (KG) |
NW (KG) |
Wrapper |
Volume (m3) |
Qty./20\'FCL?(set) |
Qty./40\'FCL?(set) |
NBDJS513-RYG |
900*690*230? |
1 | 28 | 23 | CTN | 0.14 | 214 | 433 |
5.?Competitive Advantages
Standard: GB2003-14887: CE. Well-packed with K carton+ EPE Delivery on time&Support shipping via UPS/DHL/EMS/Sea/Air,etc Reply you within 24hours Free maintenance during warranty period if any problems except man-made or natural factors. Video to show you how to use our traffic controller system if necessary6.?Application
? ? 1) Pedestrian Road.
? ? 2) Traffic road
? ? 3)?Train station
7.Test image
8.?Dimensions
9.?Cold Steel Housing Traffic Light Countdown Timer ,Dia 800*600*70mm For Traffic Road
We are devoting to----Green Light,Green Life.
? ? ?Dear friend, Good mood and?thank you so much for geting through our LED Countdown?time .
More products details?please see our website, and feel free to contact Noble. And ?us?shall be
delighted to help you, with the?best price&services. Thank you in advance!?
