30-185-740 Step Tile Roll Forming Machine Step Tile Hydraulic Decoiler
- T/T L/C D/P D/A
- 7 days
You May Like
-
0.4mm - 0.6mm Roofing Tile Making Machinery PPGI Steel Coil Forming Line
-
7.5Kw Glazed Tile Roll Forming Machine Roof Panel Forming Line For Prefabricated Houses
-
Auto Roofing Tile Roll Forming Machine Double Layer Roof Tile Machinery
-
Auto Corrugated Glazed Tile Roll Forming Machine 45# Forged Steel Roller 18m/min
-
0.4mm - 0.6mm Ridge Cap Roll Forming Machine , Roof Tile Making Machine
-
AMS Control Roofing Tile Roll Forming Machine Roofing Tile Hydraulic
Product Details
| Brand Name | HRF | Place of Origin | China | |
| Model Number | 30-185-740 |
Product Description
Certification:CE
Descrition:
Main power:5.5KW Single row chain drive Roller station:15 stations Size of machine: approx 9m*1.7m*1.4m Weight:7000Kg Roll speed:12-15m/min Working speed:2--3m/min Hydraulic power:5.5KW Cutting blade material:Cr12,quenched 58-62 Sheet thickness:0.4-0.6mm prepaited steel width of raw material: 925mm Chrome plated 0.05mm on the surface of rollers material of roller: 45#forge steel Material of blade: Cr12, quenched 58-62 No abrading on the surface Yaskawa inverter Computer: PLC, Panasonic/Siemens The computer is LCD touch-screen, Electronic requirements:380V,50Hz,3PhaseEquipment components:
Single head hydraulic decoiler, roll forming machine, hydraulic station, PLC cabinet, hydraulic shear, pressing unit,output table(2)
Applications:
Roof panels,Roofing Tiles
Step roofing panels
Specifications:
Drawing:
Main Technical specifications:
|
NO. |
Items |
Unit |
Main specification |
|
1 |
Suitable Material |
mm |
0.35-0.75mmx 925mm |
|
2 |
Forming speed |
m/min |
18 |
|
3 |
Roll station |
/ |
15 stations |
|
4 |
Main power |
kw |
7.5 |
|
5 |
Hydraulic power |
kw |
4 |
|
6 |
Control system |
/ |
PLC, panasonic/Siemens |
|
7 |
Drive |
/ |
by chain |
|
8 |
Way of decoiler |
5T hydraulic decoiler |
Flowchart:
5 hydraulic decoiler---Guiding---Film covering--- Roll forming machine-- pressing----hydraulic cutting--- Output tables
Competitive Advantage:
1: We? exported the step tile machine to South Africa,Zambia and Ghana and so on and gained good reputation from our customers.
2: With top quality and reasonable price we would like to build a long term business relations with some overseas companies
