High Power 30W COB Commercial Led Flood Lights 3000lm IP65 RoHS

Brand Name	TLD		Place of Origin	China
Model Number	TLD-TG245-20W 30W 40W

Delivery Time:Samples will be sent in 3-5 working days
Certification:CE/RoHS/C-Tick/SAA

High Power 30W COB Commercial Led Flood Lights 3000lm IP65 RoHS
?

Specifications:
?

Product?Name:	20W?30W?40W?LED?flood?light
Model?No.:	TLD-TG245-20W?30W?40W
Input?Voltage:	AC85-265V?50/60Hz
LED?QTY:?	20pcs*1W?/30pcs*1W/40pcs*1W(?multi-chip?COB)
Total?Power:	24W/35W/45W
Driver?Efficiency:	>85%
Harmonic?distortion	<10%
Power?Factor(PF):	>0.95
LED?Efficiency:	100-110lm/W
Initial?Lumen:	>2000lm/3000lm/4000lm
LED?Work?Voltage:	30-36V
Color?Temperature:	WW:2700-4000K,PW:4500-5500K,CW:6000-7500K,??Red,?Yellow, ???Blue,?Green,?Amber,?RGB
Distribution?of?the?light:	LED+?secondary?distribution?of?the?light?reflector
The?curve?of?light?distribution:	symmetric?expression/circular?glare
Protected?Grade:	IP65
Working?Temperature:	-44-50°C
Working?Humidity:	10?~?90%RH
Material?for?light?:	High?purity?Aluminum+?toughened?glass
Case?Color?Available:	?Gray
Beam?Angel?Available:	120°
Life?Span:	?>50000hours
N.W/G.W:	2.80KGS/3.50KGS
Product?Dimension:	L245*W315*H65mm
Warranty:	3?years
Certificate??Approved:	CE-EMC,CE-LVD,?RoHS,?C-tick,?SAA

Application:

LED Tunnel Lightis available for Building,factory,storage room,public ,parking lot ,exhibition building,domestic block,gymnasium,gas station,Square,advertise,Lawn,Super market Wharf ,Garden and other lighting places.

Description:

?

Adopt Super Brightness Multi-Chip LED Lighting Source, encapsulation by ourselves, Long lifespan, Energy saving, Environment friendly, High efficiency, No strobe, No ghosting, No UV, IR.
? TLD series Led Tunnel Light integrate LED lighting source and the cover of the light, the advantages are no needing extra cover, the volume is small and the weight of the body is light. Which make the led light perfect.
? The Lighting source of the led tunnel light is using super bright big size LED chip, It’ s single led chip with top quality which lumen is up to 120lm/W, Using high efficiency PC lens and sand blast oxidation light cover which can solve the problems such as light loss and color shading. It can assure the uniformity of flux and color.
? Using high efficiency thermal conductivity silicon, it’s assured the heat sink of the light, the temperature of the junction is not pass 65 ℃, which is effective controlled the light degradation, the lifespan for the led light is over 30000 hours.
? High efficiency intelligence Driver and very professional design which makes the surface temperature of the light body less than 60℃. The life span for the driver is over 30000 hours.
? The range for the input voltage is wide. Which make the led Tunnel Lightare available for the global. Unique protection
