Horizontal Mounting Portable Mini Hydraulic Power Packs 12V With 0.8Kw Motor Fireproof

Single Acting Hydraulic Power Pack with Plastic Tank

This Hydraulic Power Unit is to operate single acting cylinders,?
DC 12V Hydraulic power unit.??
DC12V 0.8Kw?motor?

0.75cc/r gear pump.
1.5 Litre plastic tank with drain plug.?
Hydraulic Power pack complete with suction filter, remote,return oil pipe and air breather.?
Mounting: Horizontal?Mounting.?
Max pressure: 160 bar.
Relief valve: RV2-08. ?set pressure 180 bar, but adjustable from 50-210 bar as standard for each single acting hydraulic power pack.

Check Valve:CV2-08. Non-return Valve to keep cylinder stay .
Flow Rate: 2.5 l/min.
Relief valve and check valve for all standard power unit
Oil Port size :1/4\"BSP
Power Packs suitable for all kinds of single?acting ?Hydraulic cylinders.

Basic Information

Commercial Terms

DC12V Power Pack Drawing:

Hydraulic Power Pack Assemble Plant:

Competitive Advantage:

1. TIANDI hydraulic is one of earliest factories of hydraulic packs and units. We have a professional team for raw material purchasing to control the cost. Our works are all well trained and effective. All above these makes our price very competitive.

2. Our export department staff is very professional and effective. They are good at export processing, any problems and questions about products or processing, or paper woks, you can contact and count on them.
