Home > Products > Ribbon Blender Machine > Single Screw Ribbon Blender Mixer / Particles Spiral Mixing Machine
Single Screw Ribbon Blender Mixer / Particles Spiral Mixing Machine
- T/T L/C D/P D/A
- 7 days
You May Like
-
Stainless Steel 304 / 316L Industrial Grinder Machine Dyadic Type
-
Inside Stirring Paddles Ribbon Blender Machine Stainless Steel
-
Stirring Paddles Vertical Mixer / Vertical Blender Powder Can Mix Coagula
-
Cyclone - Seperating Pulse Automatic Milling Machine Dust Collecting
-
Spiral Ribbon Powder Blender Equipment / Horizontal Ribbon Mixer
-
Rotate Forced Stirring V Mixer Machine for Powder in Chemical And Food Industry
Product Details
| Brand Name | Jiangyin Hallo | Place of Origin | China | |
| Model Number | DLH |
Product Description
Certification:CE/ISO
Single Screw ribbon blender mixer / particles spiral mixing machine
Main Application :
As a new type high efficience and high precision mixing equipment, Spiral Mixing Machine can machine is widely
used for mixing of powdery or paste materials in pharmaceutical, chemical and feed
trades etc.
Working principle :
The machine consists of single screw and type S blade. It is featured with large agitating
scope, high mixing speed, no dead angle. It is more suitable for mixing of materials with
a great disparity in specific weight and mixing proportion
Technical Parameters:
| model |
Total volume
(m3) |
max loading volume |
max loading weight |
mixing time(min) |
material ?size(mesh) |
motor ?power(kw) |
overall dimension |
weight(kg) |
| DLH100 | 100L | 60L | 60KG |
0-99
|
20-350 | 2.2 |
700×1400
|
300 |
| DLH200 | 200L | 120L | 120KG |
0-99
|
20-350 | 3 |
890×1930
|
600 |
| DLH300 | 300L | 180L | 180KG |
0-99
|
20-350 | 3 |
1010×1850
|
600 |
| DLH500 | 500L | 300L | 300KG |
0-99
|
20-350 | 4 |
1180×2290
|
800 |
| DLH1000 | 1000L | 600L | 600KG |
0-99
|
20-350 | 5.5 |
1500×2700
|
1200 |
| DLH2000 | 2000L | 1200L | 1200KG |
0-99
|
20-350 | 11 |
1900×3500
|
1800 |
| DLH3000 | 3000L | 1800L | 1800KG |
0-99
|
20-350 | 15 |
2120×4000
|
2200 |
| DLH4000 | 4000L | 2400L | 2400KG |
0-99
|
20-350 | 18.5 |
2200×4050
|
2600 |
| DLH5000 | 5000L | 3000L | 3000KG |
0-99
|
20-350 | 22 |
2530×4300
|
3000 |
| DLH6000 | 6000L | 3600L | 3600KG |
0-99
|
20-350 | 30 |
2850×4780
|
3500 |
Features:
|
Performance & Technical Features · Efficient capacity 100-30000liters · Drive 1.5kw-45kw · Efficiency 10-30mins/batch ? (Depending on recipe and configuration) · Gentle mixing&low power ??consumption · Minimum heat generation · No leftover and quick discharge Function configuration · Heating/cooling jacket · Sealing device · Spraying device · Cleaning device · Sampling device · Drive control |
Discharge · Discharge control · Manual self-lock · Pneumatic driven · Electric driven · Discharge valve · Dislocation valve · Half spheric valve · Butterfly valve · Slide valve Doors/opening on mixer · Standard flange connection · Quick-opening feeding inlet · Exhaust port · Cleaning doors |
Material standard · Carbon/mild steel · Contact parts SS 304 · All mixing tank SS 304 · Contact parts SS 316L · All mixing tank SS 316L · Special material · Anti-corrosion material cladded · Abrasion proof material painted · Functional |
Customer?Service
Our?excellent?customer?service?also?includes?the?installation?of?our?machines.?To?ensure?smooth?
performance,?we?also?provide?a?one?year?warranty,?and?a?spare?set?of?wearing?parts?to?our?cus
