Four -shuttle circular loom
Negotiable
/ Set
1 Set(Min.Order)
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Brand Name | SL | Place of Origin | China | |
| Model Number | SL-SC-4/750 |
Product Description
Plane cam and connecting rod rolling wheel transmission, which is the most advanced technology are adopted, making it easy and stable to run.
- Rolling transmission is adopted in entire structure instead of slide block and slide rod, which doesn’t need lubricant and decreases the wearing part.
- It's an environmental product whose noise is not more than 82dB(A).
- Low strength plastic yarn which is made from 100% regenerated plastic can be adopted to weave.
- It is high-efficient and energy economical. The highest rotation speed of the main motor can reach 180r/min and the power is 1.5/2.2kw, which can save 10 thousand degree of electricity one year.
-As required, equipped with electronic intelligent fabric-lifting unit which is featured with the compensation setting to the warp/weft density casually.
- It is the latest type circular loom
|
Model |
SL-SC-4/750 |
|
Number of shuttle (pcs) |
4 |
|
Folding width of weaving(mm) |
350-750 |
|
Max.number of warp |
768 |
|
Rotational speed of main engine(r/min) |
140-180 |
|
Production (m/min) |
1.4-1.8 |
|
Main motor power (kw) |
1.5/2.2 |
|
Total power(kw) |
2/2.7 |
|
Noise DB(A) |
<85 |
|
Dimensions (L×W×H)mm |
8300x2200x2730 |
|
Weight(About)kg |
2000 |
